Power LCR Meter PCB [04103251]
The PCB for the Power LCR Meter.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
156 x 118mm.
|
 |
Versatile Waveform Generator PCB [04104251]
101.5 x 73.5mm.
|
 |
High-Bandwidth Differential Probe PCB [9015-D or 9051-D]
The PCB for the High-Bandwidth Differential Probe.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
56.5 x 82.5mm.
|
 |
RFID Programmable IR Fob Remote PCB [15109231]
The PCB for the RFID-programmable IR Keyfob Remote.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
30.5 x 52mm.
|
 |
Programmable Frequency Divider/Counter PCB [04108241]
The PCB for the USB-programmable Frequency Divider.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
84 x 35.5mm.
|
 |
Digital Capacitance Meter PCB [04111241]
The PCB for the Digital Capacitance Meter project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
80 x 100mm.
|
 |
40A Current Probe PCB [9049-01]
The PCB for the 5MHz 40A Current Probe project (codd 9049-01).
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
56.5 x 76.5mm.
|
 |
Battery Powered Model Train transmitter PCB [09110241]
The transmitter PCB for the Battery-Powered Model Train project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
49 x 36mm.
|
 |
Battery Powered Model Train TH receiver PCB [09110242]
The through-hole receiver PCB for the Battery-Powered Model Train project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
74 x 23mm.
|
 |
Battery Powered Model Train SMD receiver PCB [09110243]
The SMD receiver PCB for the Battery-Powered Model Train project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
23 x 30mm.
|
 |
Battery Powered Model Train charger PCB [09110244]
The Charger PCB for the Battery-Powered Model Train project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
63 x 32mm.
|
 |
Compact HiFi Headphone Amplifier PCB [01103241]
The PCB for the Compact Hifi Headphone Amplifier.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
148 x 80mm
|
 |
Capacitor Discharger PCB [9047-01]
The PCB for the Capacitor Discharger project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
90 x 50mm.
|
 |
Pico Computer PCB [07112234]
The main Pico Computer Board PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
98 x 68mm.
|
 |
PWM Audio PCB [07112238]
The PWM Audio PCB described in the Digital Video BackPack article (07112238).
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
32 x 17mm.
|
 |
Mk2 VSD PCB [11111241 or 9048-02]
The PCB for the new Variable Speed Drive for Induction Motors.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay
150 x 205mm.
|
 |
Surf Sound Simulator PCB [01111241]
The PCB for the new Surf Sound Simulator.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay
236 x 80mm.
|
 |
FlexiDice PCB set [08107241-2]
A set of two PCBs, both 34 x 62mm with a red solder mask, for the FlexiDice project.
Double-sided PCBs with plated through holes, red solder mask and silkscreen overlay.
|
 |
Filament Dryer Control PCB [28110241]
The control PCB for the 3D Printer Filament Dryer.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay
126 x 93mm.
|
 |
8-Channel Learning Remote Recevier PCB [15108241]
The PCB for the 8-Channel Learning IR Remote Receiver.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay
130 x 101.5mm.
|
 |
Dual Rail Load Protector PCB [18109241]
The PCB for the Dual-Rail Load Protector.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay
96 x 69mm.
|
 |
Micromite Explore-40 PCB [07106241]
The Explore 40 PCB.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay
51 x 21mm.
|
 |
Pico BackPack stereo jack socket adaptor PCB [07101222] and connectors
The small (20 x 15mm) jack socket adaptor PCB for the Pico BackPack, described in the October 2024 issue, plus the two onboard connectors (the jack socket and a 3-pin header).
Please note: the jack socket pins are a tight fit in the PCB holes, but they will go in if they are properly lined up. You may need to push it down fairly hard but make sure all the socket pins are straight first.
|
 |
Compact OLED Clock & Timer PCB [19101231]
The PCB for the Compact OLED Clock/Timer, which doubles as the front panel.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
83 x 53mm
|
 |
PicoMSA PCB [04109241]
The PCB for the Raspberry Pi Pico based Mixed Signal Analyser.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
77 x 148mm.
|
 |
Discrete Ideal Bridge Rectifier TH PCB [18108241]
The Discrete Ideal Rectifier PCB that uses all through-hole parts.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
87.5 x 54.5mm
|
 |
Discrete Ideal Bridge Rectifier SMD PCB [18108242]
The Discrete Ideal Rectifier PCB that uses mostly SMD parts, with a few through-hole devices like the power Mosfets.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
54.5 x 54.5mm
|
 |
Guitar Pickguard - Jazz Bass [23109241]
The Jazz Bass guitar custom pickguard.
Double-sided PCB with plated through holes, lead-free finish, black solder mask and silkscreen overlay.
127 x 105.5mm.
|
 |
Guitar Pickguard - J&D T-Style Bass [23109242]
The J&D Luthiers T-Style bass guitar custom pickguard.
Double-sided PCB with plated through holes, lead-free finish, black solder mask and silkscreen overlay.
200.5 x 87.5mm.
|
 |
Guitar Pickguard - Music Man Stingray Bass [23109243]
The Music Man Stingray bass guitar custom pickguard.
Double-sided PCB with plated through holes, lead-free finish, black solder mask and silkscreen overlay.
190 x 71mm.
|
 |
Guitar Pickguard - Fender Telecaster [23109244]
The Fender Telecaster electric guitar custom pickguard.
Double-sided PCB with plated through holes, lead-free finish, black solder mask and silkscreen overlay.
28.5 x 148mm.
|
 |
Styloclone PCB, case version [23106241]
The Styloclone PCB. This is the version that fits in the instrument case.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
179 x 123mm.
|
 |
Styloclone PCB, benchtop version [23106242]
The Styloclone PCB. This is the version that sits on a benchtop on tapped spacer feet.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
207 x 124.5mm.
|
 |
Dual Mini LED Dice PCB, white, for TH LEDs [08103241]
The PCB for the Dual Mini LED Dice. This is the version that uses 3mm through-hole LEDs, with a white solder mask.
59.5 x 26mm
|
 |
Dual Mini LED Dice PCB, white, for SMD LEDs [08103242]
The PCB for the Dual Mini LED Dice. This is the version that uses SMD LEDs, with a white solder mask.
59.5 x 26mm
|
 |
Dual Mini LED Dice PCB, black, for TH LEDs [08103241]
The PCB for the Dual Mini LED Dice. This is the version that uses 3mm through-hole LEDs, with a black solder mask.
59.5 x 26mm
|
 |
Dual Mini LED Dice PCB, black, for SMD LEDs [08103242]
The PCB for the Dual Mini LED Dice. This is the version that uses SMD LEDs, with a black solder mask.
59.5 x 26mm
|
 |
180-230V DC Motor Speed Controller PCB [11104241]
The PCB for the 180-230V DC Motor Speed Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
201 x 134mm.
|
 |
Automatic LQ Meter main PCB (CSE240203A)
The PCB for the Automatic LQ Meter.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
138 x 75.5mm.
|
 |
Mains Power-Up Sequencer PCB [10108231]
The PCB for the Mains Power-Up Sequencer project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
203 x 134mm.
|
 |
2-Way Passive Crossover PCB [01205141]
PCB for the 2-Way Crossover, to suit the Majestic & Senator Speakers (and others).
Extra-thick (2mm) double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
We've had these PCBs made thicker for improved shock and vibration resistance. The tracks are paralleled top and bottom for lower resistance and higher reliability.
107 x 120mm.
|
 |
ESR Test Tweezers four PCB set
A set of four PCBs for the ESR Test Tweezers: the main PCB (04105241), protective back panel PCB (04105242) and two arms (04106212), all with white solder mask and black silkscreen printing.
|
 |
USB-C Serial Adaptor PCB (black) [24106241]
The PCB for the adjustable USB Type-C to Serial Adaptor.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
16 x 22mm.
|
 |
USB-C Serial Adaptor PCB (green) [24106241]
The PCB for the adjustable USB Type-C to Serial Adaptor.
Double-sided PCB with plated through holes, GREEN solder mask and silkscreen overlay.
16 x 22mm.
|
 |
DC Supply Protector PCB (adjustable SMD version) [08106241]
The PCB for the adjustable SMD version of the DC Supply Protector.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
51 x 23mm.
|
 |
DC Supply Protector PCB (adjustable TH version) [08106242]
The PCB for the adjustable through-hole version of the DC Supply Protector.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70.5 x 35.5mm.
|
 |
DC Supply Protector PCB (fixed TH version) [08106243]
The PCB for the fixed through-hole version of the DC Supply Protector.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70.5 x 35.5mm.
|
 |
WiFi DDS Function Generator PCB [04104241]
The PCB for the WiFi DDS Function Generator.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
149 x 108mm.
|
 |
Advanced/ESR Test Tweezers back panel PCB (blue) [04105242]
A small blue PCB that can be stuck to the back (cell holder) of either the ESR Test Tweezers or Advanced Test Tweezers to protect the circuitry in use.
It can also be soldered via pins through the small pads provided, down to the main PCB.
36 x 28mm.
|
 |
Compact Frequency Divider PCB [04112231]
The PCB for the 10MHz to 1MHz/1Hz Frequency Divider.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
64 x 37.5mm
|
 |
Fan Speed Controller Mk2 PCB [10104241]
The PCB for the Mk2 Fan Speed Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
94 x 79mm.
|
 |
Skill Tester 9000 PCB [08101241]
The Skill Tester 9000 PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
174 x 177mm.
|
 |
Pico Gamer PCB [08104241]
The PCB for the Pico Gamer project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
188 x 80mm.
|
 |
ESP32-CAM BackPack PCB [07102241]
The PCB for the ESP32-CAM LCD BackPack.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
99 x 55mm.
|
 |
Calibrated Measurement Microphone PCB (SMD version) [01108231]
The SMD version PCB for the Calibrated Microphone.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
64 x 13mm.
|
 |
Calibrated Measurement Microphone PCB (TH version) [01108232]
The through-hole version PCB for the Calibrated Microphone.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
99 x 13mm.
|
 |
Laser Communicator transmitter PCB [16102241]
The transmitter PCB for the Laser Communicator project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
81.5 x 55.5mm.
|
 |
Laser Communicator receiver PCB [16102242]
The receiver PCB for the Laser Communicator project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
80 x 37.5mm.
|
 |
Digital Video Terminal PCB [07112231]
The PCB for the Pico Digital Video Terminal project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
98 x 68mm.
|
 |
Nunchuck RGB LED Lights PCB [16103241]
The PCB for the Wii Nunchuk RGB Light Driver project.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
213 x 158mm.
|
 |
Arduino for Arduinians six PCB pack
This pack includes six PCBs, to build Projects 3, 13, 14, 18, 19 and 26 in John Boxall's book (one of each).
|
 |
Arduino for Arduinians Project 27 PCB
A single PCB for Project 27 in John Boxall's book. This is the Giant Seven-Segment LED Display.
It's sold separately as readers may wish to build more than one.
|
 |
Microphone Preamplifier full PCB [01110231]
The Microphone Preamplifier PCB that fits in the diecast aluminium case.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
85 x 110mm.
|
 |
Microphone Preamplifier embedded PCB [01110232]
The Microphone Preamplifier PCB that is designed to be integrated with other equipment (the 'embedded' version).
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
85 x 110mm.
|
 |
Model Railway Points Controller receiver PCB [09101242]
The receiver PCB for the Model Railway Point Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
56 x 45mm.
|
 |
Model Railway Points Controller transmitter PCB [09101241]
The transmitter PCB for the Model Railway Point Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
74 x 47mm.
|
 |
Raspberry Pi Clock Radio main PCB [19101241]
The main PCB for the Raspberry Pi-based Clock Radio project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
150 x 83mm.
|
 |
Raspberry Pi Clock Radio display PCB [19101242]
The LED display PCB for the Raspberry Pi-based Clock Radio project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
150 x 44mm.
|
 |
USB keyboard Adaptor for VGA PicoMite PCB [07111231]
The PCB for the VGA PicoMite or keyboard-only version of the PS/2 to USB Keyboard Adaptor.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
42 x 66mm.
|
 |
ps2x2pico PS/2 Adaptor PCB [07111232]
The PCB for the ps2x2pico or mouse and keyboard version of the PS/2 to USB Keyboard Adaptor.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
58 x 52mm
|
 |
Multi-channel Volume Control volume PCB [01111221]
The main volume control PCB for the Multi-channel Volume Control.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
82 x 94mm.
|
 |
Multi-channel Volume Control control PCB [01111222]
The power supply and control PCB for the Multi-channel Volume Control.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
87 x 50mm.
|
 |
Multi-channel Volume Control OLED PCB [01111223]
The OLED control PCB for the Multi-channel Volume Control.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
51 x 76mm.
|
 |
Secure Remote Switch receiver PCB [10109231]
The receiver PCB for the Secure Remote Switch.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70 x 96.5mm.
|
 |
Secure Remote Switch transmitter PCB [10109232]
The module-based transmitter PCB for the Secure Remote Switch.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
30 x 39.5mm.
|
 |
Secure Remote Switch transmitter PCB [10109233]
The discrete-component-based transmitter PCB for the Secure Remote Switch.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
30 x 39.5mm.
|
 |
Ideal Bridge Rectifier PCB, 28mm spade version [18101241]
The Ideal Diode Bridge PCB designed to replace a square bridge rectifier with spade terminals.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
28 x 28mm.
|
 |
Ideal Bridge Rectifier PCB, 21mm square PCB pin version [18101242]
The Ideal Diode Bridge PCB designed to replace a square bridge rectifier with leads.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
22 x 22mm.
|
 |
Ideal Bridge Rectifier PCB, 5mm pitch SIL version [18101243]
The Ideal Diode Bridge PCB designed to replace an inline bridge rectifier with leads.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
23 x 20mm.
|
 |
Ideal Bridge Rectifier PCB, mini SOT-23 version [18101244]
The Ideal Diode Bridge PCB designed to replace a W02/W04 style bridge rectifier or be used anywhere you need a small rectifier.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
9 x 15mm.
|
 |
Ideal Bridge Rectifier PCB, standalone D2PAK SMD version [18101245]
The standalone Ideal Diode Bridge PCB with SMD components that can handle a bit more current.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
59 x 36mm.
|
 |
Ideal Bridge Rectifier PCB, standalone TO-220 through-hole version [18101246]
The standalone Ideal Diode Bridge PCB with through-hole components that can handle substantially more current than the others.
Double-sided PCB with 70μm copper, plated through holes, green solder mask and silkscreen overlay.
38 x 28mm.
|
|
Ideal Bridge Rectifier PCB, standalone TO-220 through-hole version, light copper (35um) [18101246]
The standalone Ideal Diode Bridge PCB with through-hole components. This is a lower cost version with standard 35µm-thick copper, suitable for applications up to 10A.
Double-sided PCB with 35μm copper, plated through holes, green solder mask and silkscreen overlay.
38 x 28mm.
|
 |
Coin Cell Emulator PCB [18101231]
The PCB for the Coin Cell Emulator.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
78 x 44mm.
|
 |
Pico (2) Audio Analyser PCB [04107231]
The PCB for the Pico Audio Analyser or Pico 2 Audio Analyser.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
83 x 50mm.
|
 |
Thermocouple Thermometer/Thermostat main PCB [04108231]
The main PCB for the Thermometer/Thermostat.
Double-sided PCB with plated through holes, red solder mask and silkscreen overlay.
98 x 70mm.
|
 |
Thermocouple Thermometer/Thermostat front panel PCB [04108232]
The front panel/switch PCB for the Thermometer/Thermostat.
Double-sided PCB with plated through holes, red solder mask and silkscreen overlay.
19 x 22mm.
|
 |
Modem Watchdog PCB [10111231]
The PCB for the Modem/Router Watchdog.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
51 x 42mm.
|
 |
Magnetic levitation demonstration PCB
The PCB for the Circuit Notebook entry titled "Magnetic levitation demonstration" in the November 2023 issue.
Double-sided PCB (single-sided design) with plated through holes, green solder mask and silkscreen overlay.
47 x 57mm
|
 |
Discrete microamp LED flasher PCB
The PCB for the Circuit Notebook entry titled "Discrete microamp LED flasher" in the November 2023 issue.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
16.5 x 18mm.
|
 |
2m FM DDS Test Generator PCB [06107231]
The PCB for the 2m VHF FM Test Signal Generator.
Double-sided PCB with plated through holes, red solder mask and silkscreen overlay.
50 x 70mm.
|
 |
TQFP-32 Programming Adaptor PCB [24108231]
The 32-pin TQFP Programming Adaptor board.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
95 x 82.5mm.
|
 |
TQFP-44 Programming Adaptor PCB [24108232]
The 44-pin TQFP Programming Adaptor board.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
95 x 82.5mm.
|
 |
TQFP-48 Programming Adaptor PCB [24108233]
The 48-pin TQFP Programming Adaptor board.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
95 x 82.5mm.
|
 |
TQFP-64 Programming Adaptor PCB [24108234]
The 64-pin TQFP Programming Adaptor board.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
95 x 82.5mm.
|
 |
30V 2A Bench Supply revised main PCB [04107223]
The revised main PCB for the 30V 2A Bench Supply.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
100 x 140mm.
|
 |
30V 2A Bench Supply front panel control PCB [04105222]
The control PCB for the 0-30V 0-2A Bench Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
56 x 61mm.
|
 |
Salad Bowl Speakers Crossover PCB [01109231]
The crossover PCB for the Salad Bowl Speakers.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
98 x 104mm.
|
 |
PIC Programming Adaptor PCB [24105231]
The PCB for the new PIC Programming Adaptor.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
65.5 x 66mm.
|
 |
Voltage Inverter/Doubler PCB [04107222]
The PCB for the Voltage Doubler or Inverter.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
37 x 42.5mm.
|
 |
Watering System Controller PCB [15110231]
The Watering System Controler PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
132 x 152mm.
|
 |
ESR Meter add-on PCB for Digital LC Meter [04106183]
The separate Arduino ESR Meter PCB.
Double-sided PCB (single-sided design) with plated through holes, green solder mask and silkscreen overlay.
86.5 x 56mm.
|
 |
Combined LC/ESR Meter PCB [04106182]
The combined LC and Arduino ESR Meter PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
68.5 x 115.5mm.
|
 |
Large Dynamic RFID Tag PCB [06101232]
The larger (credit card sized) PCB for the Dynamic NFC/RFID Tag.
Double-sided PCB with plated through holes, black solder mask and silkscreen overlay.
86 x 54mm.
|
 |
Small Dynamic RFID tag PCB [06101231]
The smaller PCB for the Dynamic NFC/RFID Tag.
Double-sided PCB with plated through holes, purple solder mask and silkscreen overlay.
22 x 31mm.
|
 |
Reciprocal Frequency Counter main PCB (CSE230101C)
The main PCB for the Reciprocal Frequency Counter.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
76 x 63.5mm.
|
 |
Raspberry Pi Thermal Camera PCB [04105231]
The PCB for the RPi Thermal Camera.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
60 x 52.5mm.
|
 |
Model Railway Uncoupler PCB [09105231]
The control PCB for the Model Railway Uncoupler.
Double-sided PCB (single-sided design) with plated through holes, green solder mask and silkscreen overlay.
40 x 34mm.
|
 |
Oscillator-Based Vibrator Mosfet replacement PCB [18106231]
The PCB for the vibrator replacement using TO-220 Mosfets, as described in the July 2023 issue.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
33 x 45.5mm.
|
 |
Basic RF Signal Generator main PCB (CSE221001]
The PCB for the AD9834-based RF Signal Generator.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
59 × 65mm
|
 |
Loudspeaker Testing Jig PCB [04106231]
The PCB for the Loudspeaker Test Jig.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
99.5 x 189.5mm
|
 |
Vibrator Mosfet replacement PCB set [18105231+18105232]
Two PCBs used to build a Mosfet-based replacement for a radio vibrator, as described in the June 2023 issue.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
Both 34 x 53mm.
|
 |
Wideband Fuel Mixture Display PCB [05104231]
The PCB for the WFMD.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
103.5 x 63.5mm.
|
 |
Dual RF Amplifier PCB [CSE220602A]
The Dual RF Amp PCB.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
38 x 38mm.
|
 |
GPS-Disciplined Oscillator PCB [04103231]
The GPSDO PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
100 x 55mm
|
 |
Songbird PCB [08103231]
The Songbird PCB, available in four colours (choose below).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
61 x 75mm.
|
 |
Automated Test Bench Swiss Army Knife PCB [04110221]
The TestBench Swiss Army Knife circuit board.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
142 x 83.5mm
|
 |
Silicon Chirp cricket PCB [08101231]
The PCB for Silicon Chirp, the pet cricket.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
93 x 30.5mm.
|
 |
Digital Potentiometer PCB (SMD version) [01101231]
The SMD PCB for the Digital Volume Control Potentiometer.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
25.5 x 36.5mm.
|
 |
Digital Potentiometer PCB (TH version) [01101232]
The through-hole PCB for the Digital Volume Control Potentiometer.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
78.5 x 57mm.
|
 |
Model Railway Turntable contact PCB [09103232]
The contact PCB for the Model Railway Turntable.
Single-sided PCB with extra-thick gold plating.
29 x 29mm.
|
 |
Model Railway Turntable control PCB [09103231]
The control PCB for the Model Railway Turntable.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
56 x 51mm.
|
 |
Active Mains Soft Starter PCB [10110221]
The PCB for the Active Soft Starter (RevC).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
159.5 x 109mm
|
 |
Advanced SMD Test Tweezers PCB set [04106221+04106212 {blue}]
A set of PCBs to build the Advanced Test Tweezers. Includes the main board (04106221) plus two Tweezer arms (04106212) and the sticker to cover the rear of the PCB.
Double-sided PCBs with plated through holes, blue solder mask and silkscreen overlay.
One of 28 x 36mm and two of 100 x 8mm.
|
 |
Static Noughts & Crosses Computer game board PCB [08111221]
The PCB for the Noughts & Crosses Playing Computer that hosts the Hall effect sensors and LEDs. You will also need the Computer Board to complete it.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
138 x 166mm.
|
 |
Static Noughts & Crosses Computer compute board PCB [08111222]
The PCB for the Noughts & Crosses Playing Computer that hosts the controlling logic chips. You will also need the Game Board to complete it.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
138 x 124mm.
|
 |
Active Monitor Speakers power supply PCB [01112221]
The power supply PCB for the Active Crossover Amplifier used by the Active Monitor Speakers.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
147 x 60mm.
|
 |
Ultra-LD Mk.4 Amplifier PCB [01107151 RevC]
PCB for the Ultra-LD Mk.4 200W Power Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
135 x 93mm.
|
 |
Ultra-LD Mk3 200W Amplifier Module PCB [01107111]
PCB for the Ultra-LD Mk3 200W Amplifier Module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
135 x 115mm.
|
 |
Q Meter main PCB (CSE220806B or CSE220701]
The main PCB for the Q Meter which hosts most of the components.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 79mm.
|
 |
Q Meter front panel PCB (CSE220807A or CSE220704]
The front panel PCB for the Q Meter, which connects the binding posts to the circuit and also has labelling.
Double-sided black PCB with plated through holes, solder mask and silkscreen overlay. It's 1mm thick rather than 1.5/1.6mm so it looks better.
98 x 76mm.
|
 |
Raspberry Pi Pico BackPack PCB [07101221]
The PCB for the Pico BackPack or Pico W BackPack. This is also available as part of a complete kit for those projects.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 55mm
|
 |
Breadboard PSU main PCB [04112221]
The PCB for the regulator section of the Breadboard Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 54mm.
|
 |
Breadboard PSU display PCB [04112222]
The PCB for the display section of the Breadboard Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 63mm.
|
 |
Digital Boost Regulator with breakout board PCB [24110224] (purple)
The PCB for the Digital Boost Regulator/breakout board. This version has a purple solder mask to make it look a bit special.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 89mm.
|
 |
Digital Boost Regulator with breakout board PCB [24110224] (green)
The PCB for the Digital Boost Regulator/breakout board. This version has a green solder mask, as shown in the article.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 89mm.
|
 |
4-way Loudspeaker Protector PCB [01101222]
The PCB for the 4-channel version of the Multi-Channel Speaker Protector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
91 x 66.5mm.
|
 |
The Hummingbird Audio Amplifier PCB [01111211]
The PCB for the small Hummingbird audio amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
63.5 x 87.5mm.
|
 |
Two- or Three-Way Stereo Active Crossover PCB [01109211]
The PCB for the 2- or 3-Way Stereo Actrive Crossover.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
176 x 117.5mm.
|
 |
Tiny LED Icicle PCB [16111192]
Double-sided white PCB for the Xmas Icicle, with plated through holes, solder mask and silkscreen overlay.
98.5 x 98.5mm (41 x 127mm when upright).
|
 |
LC Meter Mk3 PCB [CSE220503C]
The main PCB for the new LC Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
91.5 x 63.5mm.
|
 |
LC Meter Mk3 add-on PCB [CSE200603]
A small PCB that can be used to connect leaded or SMD components to the LC Meter Mk3 for testing.
20.5 x 33mm.
|
 |
Transient DC Supply Filter PCB [08108221]
The PCB for the DC Supply Filter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
77 x 46mm.
|
 |
30V 2A Bench Supply main PCB [04105221]
The main PCB for the 0-30V 0-2A Bench Supply.
This is the original PCB design from 2022 that uses the Jaycar MM2005 transformer that has been discontinued. Unless you have a source for that transformer, you should build the revised version using the other PCB coded 04107223.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 140mm.
|
 |
PIC16F18xxx DIP Breakout PCB [24110222]
A breakout PCB for PIC16F18xxx-series microcontrollers. Suits 8, 14 & 20 pin parts from that series in DIL packages.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
15 x 35.5mm.
|
 |
PIC16F18xxx SOIC Breakout PCB [24110225]
A breakout PCB for PIC16F18xxx-series microcontrollers. Suits 8, 14 & 20 pin parts from that series in DIL packages.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
15.5 x 32.5mm.
|
 |
AVRxxDD32 TQFP Breakout PCB [24110223]
A breakout PCB for AVR-DD-series microcontrollers in TQFP-32 packages.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
16 x 53.5mm.
|
 |
Buck/Boost Charger Adaptor PCB [14108221]
The PCB for the Multi-Stage Buck-Boost Charger Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
75 x 80mm.
|
 |
Automatic Train Control PCB [09109221]
The main PCB for the Automatic Train Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 51mm.
|
 |
Chuff Sound PCB [09109222]
The Chuff Sound PCB for the Automatic Train Controller (may also be used on its own).
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
59 x 30mm.
|
 |
WiFi-Controlled DC Electronic Load main PCB [04108221]
The main PCB for the WiFi-Controlled Programmable DC Load. These PCBs have been revised to eliminate a short circuit on one track.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
107 x 81.5mm.
|
 |
WiFi-Controlled DC Electronic Load daughter PCB [04108222]
The daughter PCB for the WiFi-Controlled Programmable DC Load.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
81.5 x 66.5mm.
|
 |
WiFi-Controlled DC Electronic Load control PCB [18104212]
The control PCB for the WiFi-Controlled Programmable DC Load.
This board can also be used to build the WiFi-Controlled Programmable Hybrid Lab Bench Supply from May & June 2021, with some different linking options selected.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
167.5 x 57mm.
|
 |
New GPS-Synchronised Analog Clock Driver PCB [19109221]
The PCB for the New GPS-Synchronised Analog Clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
97 x 55.5mm.
|
 |
Mini LED Driver PCB [16106221]
The PCB for the Mini LED Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
72 x 24mm.
|
 |
Wide-Range Ohmmeter PCB [04109221]
The PCB for the Wide Range Ohmmeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
90.5 x 117.5mm.
|
 |
Secure Remote Mains Switch receiver PCB [10109211]
The receiver PCB for the Secure Remote Mains Switch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
159.5 x 109mm.
|
 |
Secure Remote Mains Switch transmitter PCB [10109212]
The transmitter PCB for the Secure Remote Mains Switch. Up to 16 transmitters can be paired to one receiver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The PCB is 1mm thick to provide sufficient clearance for the switches in the specified keyfob case.
29 x 45mm.
|
 |
Multimeter Checker & Calibrator PCB [04107221]
The PCB for the Multimeter Checker and Calibrator. Also available as part of the full kit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
65 x 58.5mm.
|
 |
VGA PicoMite PCB [07107221]
The PCB for the VGA PicoMite. Also available as part of the kit.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
124 x 69mm.
|
 |
0-110dB RF Attenuator PCB [CSE211003]
The PCB for the 110dB RF Attenuator. Also available as part of the kit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 95.5mm.
|
 |
Spectral Sound MIDI Synthesiser PCB [01106221]
The PCB for the Spectral Sound MIDI Synthesiser.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
145 x 94mm.
|
 |
High Power Buck-Boost LED Driver PCB [16103221]
The PCB for the Buck/Boost LED Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
85 x 80mm.
|
 |
Arduino Programmable Load PCB [04105221]
The PCB for the Arduino Load.
On p59 of the October 2022 issue, we described a version of this PCB with an extra terminal to allow boards to be paralleled for higher current/power handling. That is now the standard version of the board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89 x 54mm.
|
 |
Revised Intelligent Battery Charge Controller PCB [14107192]
The PCB for the Updated Battery Charge Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
111 x 81mm.
|
 |
500W Amplifier Module PCB [01107021 RevD]
The main PCB for the 500W Amplifier. Note that we sell the critical parts to build it separately (see related items link below).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
402 x 124mm.
|
 |
AM/FM DDS Signal Generator PCB [CSE211002]
The PCB for the AM/FM/DDS Signal Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
100 x 78.5mm.
|
 |
Slot Machine PCB [08105221]
The PCB for the Slot Machine.
Note that this is just the add-on board, you also need the Micromite Plus LCD BackPack (available as a partial kit, without the 3.2-inch touchscreen).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 53mm.
|
 |
Model Railway Semaphore Signal control PCB [09103221]
The control PCB for the Semaphore Signal for OO Gauge Model Railways.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
51 x 37mm.
|
 |
Model Railway Semaphore Signal blade PCB [09103222]
The blade PCB for the Semaphore Signal for OO Gauge Model Railways.
Double-sided PCB with red solder mask and white silkscreen printing.
This can be cut/snapped and filed to produce one signal blade. For maximum realism, part of it also needs to be painted black.
31 x 20.5mm.
|
 |
Capacitor Discharge Welder Power Supply PCB [29103221]
The Power Supply PCB for the CD Welder. One is needed per Welder. This is also available in a partial kit of parts.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
150 x 42.5mm.
|
 |
Capacitor Discharge Welder Control PCB [29103222]
The Control PCB for the CD Welder. One is needed per Welder. We don't offer a 'hard-to-get' parts shop item for this section of the CD Welder, just this PCB.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
150 x 42.5mm.
|
 |
Capacitor Discharge Welder Energy Storage Module PCB [29103223]
The ESM PCB for the CD Welder. 8-14 are needed per Welder (see the article for details). This is also available in a partial kit of parts.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
150 x 42.5mm.
|
 |
SMD Test Tweezers PCB set [04106211+04106212]
A set of PCBs to build the SMD Test Tweezers. Includes the main board (04106211) plus two of the Tweezer arms (04106212).
Double-sided PCBs with plated through holes, green solder mask and silkscreen overlay.
One of 28 x 26mm and two of 100 x 8mm.
|
 |
Amplifier Clipping Indicator PCB [01112211]
The Amplifier Clipping Indicator PCB. Two are needed for a stereo amplifier (or more for multi-channel; one per channel).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
54 x 60mm.
|
 |
Intelligent Dual Hybrid Power Supply PCB set
A set that includes the five PCBs needed to build one dual supply:
- One CPU PCB (01106193)
- One LCD adaptor PCB.(01106196)
- Two regulator PCBs (18107211)
- One front panel control PCB (18107212)
|
 |
Intelligent Dual Hybrid Power Supply regulator PCB [18107211]
The main regulator PCB for the Hybrid Power Supply.
You will need two if you want to build the dual-channel version as described in the magazine. It is also possible to build a single-channel version. This PCB is also available as part of a complete set for the project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
116 x 133mm.
|
 |
Intelligent Dual Hybrid Power Supply front panel control PCB [18107212]
The small front panel PCB for the Hybrid Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. This PCB is also available as part of a complete set for the project.
74.5 x 23mm.
|
 |
DSP Crossover CPU PCB [01106193]
The central processor PCB for the DSP Active Crossover. Also used for the Low-distortion DDS Signal Generator, DIY Reflow Oven Controller and Intelligent Dual Hybrid Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
60 x 62mm
|
 |
DSP Crossover LCD Adaptor PCB [01106196]
The LCD Adaptor PCB for the DSP Active Crossover. Also used for the Low-distortion DDS Signal Generator, DIY Reflow Oven Controller and Intelligent Dual Hybrid Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
51 x 13mm.
|
 |
Cooling Fan Controller & Loudspeaker Protector PCB [01102221]
The PCB for the Fan Controller & Speaker Protector.
To connect to the PWM fans, it suits either standard polarised headers that have been trimmed or Molex 47053-1000 headers (available separately from our shop).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
95 x 74mm.
|
 |
Solid State Tesla Coil driver PCBs [26102221-2]
The driver PCBs for the Solid State Tesla Coil.
This set includes the main driver board, coded 26102221 (107 x 56mm), and the small potentiometer mounting board, coded 26102222 (25.5 x 56mm)
Both are double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
|
 |
Driveway Gate Controller PCB [11009121]
The PCB for the Remote Gate Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
209.5 x 134.5mm.
|
 |
8-LED Classic Metronome PCB [23111211]
The PCB for the 8-LED Metronome described in the article titled "Two Classic LED Metronomes".
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
71 x 98mm.
|
 |
10-LED Classic Metronome PCB [23111212]
The PCB for the 10-LED Metronome described in the article titled "Two Classic LED Metronomes".
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89 x 108mm.
|
 |
Remote Control Range Extender IR-to-UHF PCB [15109212]
The UHF transmitter PCB for the Remote Control Range Extender.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
15 x 12mm.
|
 |
Remote Control Range Extender UHF-to-IR PCB [15109211]
The UHF receiver/IR transmitter PCB for the Remote Control Range Extender.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
78.5 x 47mm.
|
 |
6-way Loudspeaker Protector PCB [01101221]
The PCB for the 6-channel version of the Multi-Channel Speaker Protector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
121.5 x 66.5mm.
|
 |
Simple Linear MIDI Keyboard Joiner PCB [23101214]
The Simple MIDI Music Keyboard Joiner PCB, which is used to join multiple of the Keyboard PCBs together.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
20 x 6mm.
|
 |
SMD Trainer PCB [29106211]
A PCB for practising SMD soldering. Once assembled, it forms an LED chaser/flasher.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
71 x 40mm. Also available in a complete kit (from Altronics or our website).
|
 |
Digital Lighting Controller Translator PCB [16110206]
The PCB for the Digital Lighting Controller Translator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 45mm.
|
 |
USB Cable Tester main PCB [04108211]
The main PCB for the USB Cable Tester.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
130 x 102mm.
Note that this PCB is also available in the USB Cable Tester kit.
|
 |
Flexible Digital Lighting Controller main PCB [16110202]
The main PCB for the Flexible Digital Lighting Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
216 x 133mm.
|
 |
Flexible Digital Lighting Controller Micromite Master PCB [16110201]
Double-sided PCB for the Micromite master board used for the Flexible Digital Lighting Controller, with plated through holes, solder mask and silkscreen overlay.
86 x 55mm.
|
 |
Flexible Digital Lighting Controller CP2102 Adaptor PCB [16110204]
Double-sided PCB for the CP2102 adaptor used with the Flexible Digital Lighting Controller, with plated through holes, solder mask and silkscreen overlay.
45 x 20.5mm.
|
 |
Flexible Digital Lighting Controller LED slave PCB [16110205]
The WS2812 addressable LED controller PCB for the Flexible Digital Lighting Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
79 x 45mm.
|
 |
Model Railway Carriage Lights PCB [09109211]
The PCB for the Model Railway Carriage Lights project.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
28 x 16mm.
|
 |
The Tele-com Intercom PCB (aka OzPLAR) [12110211]
The PCB for the Tele-com. The code was accidentally written as 12110121 in the magazine.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
200.5 x 143mm.
|
 |
Touchscreen Digital Preamp PCB [01103191]
The PCB for the Touchscreen Digital Preamp. Two ribbon cable/IR adaptor PCBs are also needed, along with one of the Micromite BackPacks for control.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
205.5 x 52.5mm.
|
 |
Touchscreen Digital Preamp ribbon cable/IR adaptor PCB [01103192]
The ribbon cable adaptor PCB for the Touchscreen Digital Preamp. TWO ARE NEEDED in addition to the main board and the Micromite LCD BackPack module.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
13 x 46mm.
|
 |
Second-generation Colour Maximite 2 PCB [07108211]
The PCB for the Second Generator Colour Maximite 2 computer.
Four-layer (1.6mm-thick) PCB with plated through holes, green solder mask and silkscreen overlay.
130 x 102mm.
|
 |
Nano TV Pong PCB [08105212]
The PCB for Nano Pong using an 8-pin PIC.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
44 x 17mm.
|
 |
Battery Manager Soft Switch PCB [11104211]
The Soft Switch PCB for the Battery Manager.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
82 x 83mm.
|
 |
Battery Manager I/O Expander PCB [11104212]
The I/O Expander PCB for the Battery Manager.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
38 x 36mm.
|
 |
64-Key Arduino MIDI Shield PCB [23101211]
PCB for the 64-Key Arduino MIDI Soundboard Shield.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
68.5 x 53.5mm.
|
 |
8x8 Tactile Pushbutton Switch Matrix PCB [23101212]
PCB for the 8x8 Tactile Pushbutton Switch Matrix used with the Arduino MIDI project.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
131 x 140mm.
|
 |
Simple Linear MIDI Keyboard PCB [23101213]
The Simple MIDI Music Keyboard PCB. Also includes two of the Joiner PCBs.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
158 x 28mm.
|
 |
Battery Multi Logger PCB [11106201]
The PCB for the Battery Multi-Logger. Also used for the Multi-Purpose Battery Manager.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
85.5 x 49.5mm.
|
 |
20A DC Motor Speed Controller PCB [11006211]
The 20A DC Motor Speed Controller PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
122 x 58.5mm.
|
 |
Model Railway Level Crossing PCB [09108211]
The Level Crossing PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
48 x 43mm.
|
 |
SiLabs FM/AM/SW Digital Radio PCB [CSE210301C]
The PCB for the Silicon Labs-based FM/AM/SW Digital Radio.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
123 x 49.5mm.
|
 |
Advanced GPS Computer PCB [05102211]
The Advanced GPS Computer PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
123 x 58mm.
|
 |
Mini Arcade Pong PCB [08105211]
The Arcade Pong PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
245 x 165mm.
|
 |
8-pin PIC Programming Helper PCB [24106211]
The 8-pin PIC Programming Helper PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
37 x 72mm.
|
 |
8/14/20-pin PIC Programming Helper PCB [24106212]
The 8-in/14-pin/20-pin PIC Programming Helper PCB.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
37 x 105.5mm.
|
 |
Programmable Hybrid Lab Supply Control Panel PCB [18104211]
The Control PCB for the Programmable Hybrid Lab Power Supply with WiFi.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
167.5 x 56mm.
|
 |
Programmable Hybrid Lab Supply Regulator Module PCB [18104212]
PCB for the Regulator section of the Programmable Hybrid Lab Power Supply with WiFi.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
138 x 44.5mm.
|
 |
Variac-based Regulation Control Module PCB [10103211]
PCB for the Variac-based Mains Voltage Regulator Control Module.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
102 x 65mm.
|
 |
Digital FX Unit PCB (potentiometer-based version) [01102211]
PCB for the potentiometer-based version of the Digital FX Pedal. This PCB also requires the PIC12F1571 for potentiometer operation.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
86 x 112mm.
|
 |
Digital FX Unit PCB (switch-based version) [01102212]
PCB for the switch-based version of the Digital FX Pedal. This PCB does NOT require the PIC12F1571 for switch operation.
The 16-position rotary switch (a Lorlin BCK1001) is available from both element14 (Order Code: 2797230) and RS Components (Stock No.: 655-3162).
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
86 x 112mm.
|
 |
Refined Full-Wave Motor Speed Controller PCB [10102211]
PCB for the Refined Full-Wave Motor Speed Controller.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
103 x 81mm.
|
 |
High Current Battery Balancer PCB [14102211]
The PCB for the High-Current Four-Battery Balancer.
Four-layer PCB with plated through holes, green solder mask and silkscreen overlay.
108 x 80mm.
|
 |
Mini Isolated Serial Link PCB [24102211]
The PCB for the Mini Isolated Serial Link.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
26.5 x 23.5mm.
|
 |
Electronic Wind Chimes PCB [23011201]
The PCB for the Electronic Wind Chimes.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
147.5 x 87.5mm.
|
 |
Arduino-based Adjustable Power Supply PCB [18106201]
The PCB for the Arduino-based Power Supply shield.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
68.5 x 53.5mm.
|
 |
AM/FM/SW Single-Chip Digital Radio PCB [CSE200902A]
The PCB for the single-chip AM/FM/SW radio.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
128.5 x 89mm.
|
 |
MiniHeart PCB [01109201]
The PCB for the MiniHeart Heartbeat Simulator.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70.5 x 73mm.
|
 |
Busy Loo Indicator PCB [16112201]
The PCB for the Busy Loo Indicator (I'm Busy, Go Away!) door warning.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
39 x 49mm.
|
 |
Vintage Battery Radio Power Supply PCB [11111201]
The PCB of the Power Supply for Battery-Powered Vintage Radios.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
125 x 54.5mm.
|
 |
Dual Battery Lifesaver PCB [11111202]
The PCB for the Dual Battery Lifesaver.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70 x 32mm.
|
 |
USB SuperCodec PCB [01106201]
The main PCB for the USB Super Codec.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
99.5 x 213mm.
|
 |
USB SuperCodec Balanced Input Attenuator add-on PCB [01106202]
Double-sided PCB for the USB Super Codec Balanced Input Attenuator add-on, with plated through holes, solder mask and silkscreen overlay.
99.5 x 141.5mm.
|
 |
Tiny LED Cap PCB [16111193]
Double-sided red PCB for the Tiny LED Cap, with plated through holes, solder mask and silkscreen overlay.
55 x 57mm.
|
 |
Tiny LED Stocking PCB [16111194]
Double-sided red or green PCB for the Tiny LED Stocking, with plated through holes, solder mask and silkscreen overlay.
41 x 83mm.
|
 |
Tiny LED Reindeer PCB [16111195]
Double-sided red PCB for the Tiny LED Reindeer, with plated through holes, solder mask and silkscreen overlay.
91 x 98mm.
|
 |
Tiny LED Bauble PCB [16111196]
Double-sided PCB for the Tiny LED Bauble, with plated through holes, solder mask and silkscreen overlay. Available in red, yellow, green or blue.
52.5 x 45.5mm.
|
 |
Tiny LED Sleigh PCB [16111197]
Double-sided red PCB for the Tiny LED Sleigh, with plated through holes, solder mask and silkscreen overlay.
80 x 92mm.
|
 |
Tiny LED Star PCB [16111198]
Double-sided white PCB for the Tiny LED Star, with plated through holes, solder mask and silkscreen overlay.
57 x 54mm.
|
 |
Tiny LED Candy Cane PCB [16111199]
Double-sided red PCB for the Tiny LED Stocking, with plated through holes, solder mask and silkscreen overlay.
84 x 60mm.
|
 |
Stackable LED Star PCB [16109201]
Double-sided green PCB for the 30-LED Stackable Xmas Star (non-RGB version), with plated through holes, solder mask and silkscreen overlay.
194 x 185mm.
|
 |
RGB Stackable LED Star PCB [16109202]
Double-sided black PCB for the 30-LED RGB Stackable Xmas Star, with plated through holes, solder mask and silkscreen overlay.
194 x 185mm.
|
 |
Mini WiFi LCD BackPack PCB [24106201]
The PCB for the D1 Mini LCD BackPack with WiFi.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
99 x 54.5mm.
This PCB is also available as part of a complete kit.
|
 |
High Power Ultrasonic Cleaner main PCB [04105201]
The main PCB for the High Power Ultrasonic Cleaner.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
104 x 79mm.
|
 |
High Power Ultrasonic Cleaner front panel PCB [04105202]
The front panel control board PCB for the High Power Ultrasonic Cleaner.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
65 x 48mm.
|
 |
Shirt Pocket Audio Oscillator PCB [01110201]
The PCB for the Shirt-pocket Sized Crystal-locked Audio DDS Oscillator.
Single-sided PCB (possibly supplied as double-sided with top layer track in place of wire link) with green solder mask and silkscreen overlay.
66 x 24mm.
|
 |
8-pin ATtiny Programming Adaptor Board [01110202]
A small programming adaptor PCB for 8-pin AVR micros, as used in the Shirt-pocket Sized Crystal-locked Audio DDS Oscillator project.
Single-sided PCB (possibly supplied as double-sided with top layer tracks in place of wire links) with green solder mask and silkscreen overlay.
25.5 x 22mm.
|
 |
Night Keeper Lighthouse PCB [08110201]
The PCB for the Night Keeper Lighthouse.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay. Includes a cut/snap-off section which forms the base.
64 x 91mm.
|
 |
Switchmode 78xx Replacement PCB [18105201]
The PCB for the Switchmode 78xx Replacement project from August 2020.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
15 x 10mm, 0.8mm thick.
|
 |
Wideband Digital RF Power Meter PCB [04106201]
The main PCB for the Arduino-based Digital RF Power Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 84mm.
|
 |
Colour Maximite 2 PCB [07107201]
The main PCB for the Colour Maximite 2.
Double-sided PCB with plated through holes, blue solder mask and silkscreen overlay.
128 x 107mm.
|
 |
Ol' Timer II PCB [19104201]
The PCB for the Ol' Timer II
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Comes with red, blue or matte black solder mask (black shown; see the article for photos of the other options).
77 x 99mm.
|
 |
Infrared Remote Control Assistant PCB (Jaycar case version) [15005201]
The PCB for the IR Remote Control Assistant to suit the Jaycar remote control case (HB5610).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
63.5 x 86mm.
|
 |
Infrared Remote Control Assistant PCB (Altronics case version) [15005202]
The PCB for the IR Remote Control Assistant to suit the Altronics remote control case (H0342/H0343).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
58.5 x 86mm.
|
 |
Touchscreen RCL Box resistor PCB [04104201]
The resistor section for the RCL Box.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
114 x 57mm, 0.6mm thick.
|
 |
Touchscreen RCL Box capacitor/inductor PCB [04104202]
The capacitor/inductor section for the RCL Box.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
114 x 57mm, 0.6mm thick.
|
 |
Roadies' Test Signal Generator PCB (SMD version) [01005201]
The SMD version of the PCB for the Roadies' Test Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
47 x 47mm.
|
 |
Roadies' Test Generator PCB (through-hole version) [01005202]
The through-hole version of the PCB for the Roadies' Test Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86 x 50mm.
|
 |
H-Field Transanalyser PCB [06102201]
The PCB for the H-Field Transanalyser (AM radio alignment, testing and servicing aid).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
125 x 112mm.
|
 |
Touchscreen Car Altimeter PCB [05105201]
The PCB for the Touchscreen Car Altimeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86.5 x 49.5mm.
|
 |
DIY Reflow Oven Controller PCB Set
A set of 3 PCBs for the Solder Reflow Oven.
The set includes the CPU [01106193], Front Panel [01106195] and LCD Adaptor PCBs [01106196].
|
 |
DSP Crossover front panel control PCB [01106195]
The front panel control PCB for the DSP Active Crossover. Also used for the Low-distortion DDS Signal Generator and DIY Solder Reflow Oven Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
107 x 32mm
|
 |
7-Band Mono Equaliser PCB [01104201]
The PCB for the 7-Band Equaliser (mono version)
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
143 x 63.5mm.
|
 |
7-Band Stereo Equaliser PCB [01104202]
The PCB for the 7-Band Equaliser (stereo version)
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
157 x 86mm.
|
 |
Reference Signal Distributor PCB [CSE200103A]
The PCB for the Frequency Reference Signal Distributor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
125.5 x 60mm.
|
 |
Thermal Regulator Interface PCB [21109181]
The Interface (sensor) shield PCB used in the Thermal Regulator project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
53.5 x 68.5mm.
|
 |
Thermal Regulator Peltier Driver PCB [21109182]
The Peltier Driver shield PCB used in the Thermal Regulator project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
53.5 x 68.5mm.
|
 |
Nutube Guitar Overdrive & Distortion Pedal PCB [01102201]
The PCB for the Nutube Guitar Overdrive and Distortion Pedal.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86.5 x 112.5mm.
|
 |
Bookshelf Speaker Passive Crossover PCB [01101201]
Double-sided PCB for the passive crossover in the Easy-to-build Hifi Active Bookshelf Speakers, with plated through holes, solder mask and silkscreen overlay.
137 x 100.5mm.
|
 |
Bookshelf Speaker Subwoofer Active Crossover PCB [01101202]
Double-sided PCB for the active subwoofer crossover in the Easy-to-build Hifi Active Bookshelf Speakers, with plated through holes, solder mask and silkscreen overlay.
132 x 90mm.
|
 |
4G Remote Monitoring Station Power Control Shield PCB [27111191]
The Power Control Shield PCB for the 4G Remote Monitoring Station.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
53.5 x 68.5mm.
|
 |
Low-distortion DDS complete PCB set (5 boards) [01106192-6]
A complete set of PCBs for the Low-distortion DDS.
Includes one each of the DAC (01106192), CPU (01106193), PSU (01106194), Control (01106195) & LCD Adaptor (01106196) PCBs.
|
 |
DSP Crossover DAC PCB [01106192]
The digital-to-analog converter PCB for the DSP Active Crossover. Also used for the Low-distortion DDS Signal Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
55 x 101mm
|
 |
DSP Crossover power supply PCB [01106194]
The power supply/signal routing PCB for the DSP Active Crossover. Also used for the Low-distortion DDS Signal Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 84mm
|
 |
Nutube Stereo Valve Preamplifier PCB [01112191]
Double-sided PCB for the Low-voltage Valve Audio Preamp, with plated through holes, solder mask and silkscreen overlay.
115.5 x 105.5mm.
|
 |
Tunable HF Preamplifier PCB [06110191]
Double-sided PCB for the Tuneable HF Preamp for SDRs, with plated through holes, solder mask and silkscreen overlay.
80 x 30.5mm.
|
 |
DCC Power Shield PCB [09207181]
Double-sided PCB for the shield used in the Arduino DCC Base Station/Booster, with plated through holes, solder mask and silkscreen overlay.
68.5 x 53.5mm.
|
 |
DCC Decoder Programmer PCB [09107181]
The PCB for the DCC Programmer project. Can also be used as part of our Arduino DCC Base Station.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
69 x 54mm.
|
 |
Universal Battery Charge Controller PCB [14107191]
Double-sided PCB for the Universal Battery Charge Controller, with plated through holes, solder mask and silkscreen overlay.
110 x 81mm.
|
 |
Super-9 Stereo FM Radio PCB set
A set which includes all the PCBs needed to build a Super-9 FM Radio:
- main board [06109181], black solder mask, 313 x 142mm
- IF alignment board [06109182], 52 x 30mm
- two shield boards [06109183], 13 x 36mm
- antenna attachment board [06109184], 8 x 27mm
- potentiometer range adjustment board [06109185], 27 x 20mm
We also sell some of the hard-to-get parts and the laser-cut case pieces (including dial) separately. See the related items link below for more details.
|
 |
45V/8A Linear Bench Supply PCB [18111181]
The main board for the 45V 8A Linear Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
150 x 120mm.
Note: some constructors have found it difficult to fit diodes D5 & D6. We believe this is due to a variation in lead thickness and body size between compatible parts. The next revision of the PCB will have larger holes spaced further apart to solve this. In the meantime, try to avoid diodes with particularly large bodies for these positions.
|
 |
Tiny LED Xmas Tree PCB (green solder mask) [16111191G]
Double-sided PCB for the Tiny LED Christmas Tree, with plated through holes, solder mask and silkscreen overlay.
There are three different board colours available; this one is green (the other two are red and white).
54 x 41mm.
|
 |
Tiny LED Xmas Tree PCB (red solder mask) [16111191R]
Double-sided PCB for the Tiny LED Christmas Tree, with plated through holes, solder mask and silkscreen overlay.
There are three different board colours available; this one is red (the other two are green and white).
54 x 41mm.
|
 |
Tiny LED Xmas Tree PCB (white solder mask) [16111191W]
Double-sided PCB for the Tiny LED Christmas Tree, with plated through holes, solder mask and silkscreen overlay.
There are three different board colours available; this one is white (the other two are green and red).
54 x 41mm.
|
 |
Digital Panel Meter/USB Display PCB [18111182]
PCB for the Five-way Digital Panel Meter/USB Display.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
55 x 36mm.
|
 |
High Resolution Audio Millivoltmeter PCB [04108191]
PCB for the High-resolution Digital Audio Millivoltmeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
110 x 84mm.
|
 |
Precision Audio Signal Amplifier PCB [04107191]
PCB for the Precision Audio Signal Amplifier. Required for calibrating the High-resolution Audio Millivoltmeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
91.5 x 50.8mm.
|
 |
4DoF Simulation Seat motor controller PCB [11109191]
The main control board for the Gamer's Seat with Four DoF.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
With this board, there is no need to fit the wire links, as top layer tracks are provided in their place. Also, the high-current motor supply distribution tracks on the far left of the board are doubled up (top & bottom) to improve their current handling capability.
133.5 x 96.5mm.
|
 |
Micromite Explore 28 PCB [07108191]
PCB for the Micromite Explore-28.
Four-layer PCB with plated through holes, solder mask and silkscreen overlay.
39 x 18.5mm.
|
 |
Six-way Stereo Audio Input Selector main PCB [01110191]
The main board for the Six Input Stereo Audio Selector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
165 x 85mm.
|
 |
Six-way Stereo Audio Input Selector pushbutton PCB [01110192]
The pushbutton selector board for the Six Input Stereo Audio Selector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
106 x 37mm.
|
 |
Ultrabrite LED Bicycle Light PCB [16109191]
The PCB for the Ultrabrite LED Pushbike Light.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
22 x 12mm.
|
 |
High-current H-bridge motor controller PCB [11109192]
A motor control board, as used for the Gamer's Seat with Four DoF.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
54.5 x 23mm.
|
 |
Micromite LCD BackPack V3 PCB [07106191]
The main board for Version 3 of the Micromite LCD BackPack, with support for a 3.5-inch touchscreen and other accessories.
We sell a kit for this project as a separate item, which includes this PCB (http://siliconchip.com.au/Shop/20/5082).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 54.5mm.
|
 |
Radio Head Unit Dimmer Adaptor PCB [05107191]
The PCB for the Car Radio Dimmer Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
77 x 46.5mm.
|
 |
Pseudo-random number generator (LFSR) PCB [16106191]
The board for the Linear Feedback Shift Register pseudo-random number generator project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
91 x 63mm.
|
 |
Battery Isolator Control PCB [05106191]
The control board for the Dual Battery Isolator from the July 2019 issue. You may also need the Mosfet board, sold separately.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
98 x 79mm.
|
 |
Battery Isolator Mosfet PCB [05106192]
The Mosfet board for the Dual Battery Isolator from the July 2019 issue. You may also need the Control board, sold separately.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
98 x 79mm with 2oz (extra-thick) copper.
|
 |
Raspberry Pi Audio Breakout PCB [01106191]
The Raspberry Pi Audio board for the Speech Synthesis article in the July 2019 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
65 x 30.5mm.
|
 |
AM/FM/CW Scanning HF/VHF RF Signal Generator PCB [04106191]
The PCB for the RF Signal Generator from the June & July 2019 issues.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
152.5 x 101.5mm.
|
 |
DSP Crossover ADC PCB [01106191]
The analog-to-digital Converter PCB for the DSP Active Crossover.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
55 x 101mm
|
 |
DSP Active Crossover complete PCB set (7 boards) [01106191-6]
A complete set of PCBs for the DSP (Digital Signal Processor) Active Crossover/Equaliser.
Includes two DAC (01106192) PCBs and one ADC (01106191), PSU (01106193), CPU (01106194), Control (01106195) & LCD Adaptor (01106196) PCB.
|
 |
Steering Wheel Controller to IR PCB [05105191]
The PCB for the Steering Wheel Controls (SWC) Infrared Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
77 x 46.5mm.
|
 |
GPS "Finesaver Plus" Speedo/Clock/Volume Control PCB [01104191]
The PCB for the GPS Speedometer/Clock/Volume Control project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
91.5 x 69mm.
|
 |
433MHz Wireless Data Range Extender PCB [15004191]
PCB for the Solar-powered Data Repeater for 433MHz Remotes.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
103.5 x 78mm.
|
 |
Amplifier Bridge Adaptor PCB [01105191]
PCB for the Amplifier Bridge Adaptor from the May 2019 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 44.5mm.
|
 |
Low-cost 3.5-inch LCD Adaptor PCB for Arduino R3 [24111181]
The Adaptor PCB described in the article on low-cost 3.5-inch LCDs for Arduino or Micromite in the May 2019 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
98 x 55mm.
|
 |
Set of four Flip-Dot PCBs
A pack of PCBs for the Flipdot display which includes one coil PCB (19111181, black), one pixel PCB (19111182, black), one frame PCB (19111183, black) and one driver PCB (19111184, green).
Order multiple sets/packs if you want to build a multi-character display.
|
 |
Flip-Dot Coil PCB [19111181]
Coil Board for the Flip-Dot Display.
Double-sided black PCB with plated through holes, solder mask and silkscreen overlay.
96 x 58mm.
|
 |
Flip-Dot Frame PCB [19111183]
Frame Board for the Flip-Dot Display. Includes 8 pieces per board.
Single-sided black PCB.
75 x 72.5mm.
|
 |
Flip-Dot Pixel PCB [19111182]
Pixel Board for the Flip-Dot Display. Includes 16 pixels per board.
Single-sided black PCB.
88.5 x 84.5mm.
|
 |
Flip-Dot Driver PCB [19111184]
Driver PCB for the Flip-Dot Display.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
96 x 58mm.
|
 |
iCESTICK VGA Adaptor PCB [02103191]
PCB for the iCESTICK VGA Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 32mm.
|
 |
Low-Noise Stereo Preamplifier PCB [01111119]
PCB for the Low-Noise Stereo Preamplifier with Tone Controls.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
216 x 66mm.
|
 |
Input Switching Module PCB for the Low Noise Preamplifier [01111112]
PCB for the Preamplifier/Amplifier Input Switching Module.
PCB with plated through holes, solder mask and silkscreen overlay.
109.5 x 84.5mm.
|
 |
Input Selection Pushbutton PCB for the Low Noise Preamplifier [01111113]
PCB for the Preamplifier/Amplifier Input Selection Pushbuttons.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
66 x 24.5mm.
|
 |
Ultra-LD Mk3/Mk4 Amplifier Power Supply PCB [01109111]
PCB for the Ultra-LD Mk3 Amplifier Power Supply. Also suits the Ultra-LD Mk4.
PCB with plated through holes, solder mask and silkscreen overlay.
141 x 80mm.
|
 |
Universal Voltage Regulator PCB [18103111]
PCB for the Universal Voltage Regulator.
PCB with plated through holes, solder mask and silkscreen overlay.
71 x 35.5mm.
|
 |
Diode Curve Plotter PCB [04112181]
PCB for the Diode Curve Plotter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 59mm.
|
 |
Touch and IR Remote Control Trailing Edge Dimmer Main PCB [10111191]
Main PCB for the Versatile Trailing Edge Dimmer with Touch and/or Infrared Remote Control.
Note that you also need one Mounting PCB (10111192) to assemble this board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
66 x 104mm.
|
 |
Touch and IR Remote Control Trailing Edge Dimmer Mounting PCB [10111192]
Mounting PCB for the Versatile Trailing Edge Dimmer with Touch and/or Infrared Remote Control.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
58.5 x 104mm.
|
 |
Touch and IR Remote Control Trailing Edge Dimmer Extension PCB [10111193]
Extension PCB for the Versatile Trailing Edge Dimmer with Touch and/or Infrared Remote Control.
Note that you also need one Mounting PCB (10111192) to assemble this board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
58.5 x 104mm.
|
 |
DAB+/FM/AM Radio main PCB [06112181]
The latest version of the main PCB for the DAB+/FM/AM Radio project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
If you order this item, you will get the bare board. Nothing else is supplied or fitted. If you want a board with more components pre-soldered, order Cat SC4896 (IC1 only fitted) or SC4897 (IC1 & surrounding components fitted).
Note: you will also need to purchase the components for this board plus the Explore 100 module (http://www.siliconchip.com.au/Shop/20/3834) to complete the electronics. We have a separate kit of parts which provides some of the remaining SMDs on this board (Cat SC4904), plus we also sell a short-form kit for the Explore 100 without LCD (Cat SC3834), the dual RCA socket (Cat SC4850) and some extendable VHF whip antennas (Cat SC4847 & SC4875).
134 x 84.5mm.
|
 |
Motion-Sensing 12V Power Switch SMD PCB [05102191]
The PCB for the 12V Movement/Vibration Switch (SMD version).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
25.4 x 19.5mm.
|
 |
USB Mouse and Keyboard Interface PCB [24311181]
The PCB for the USB Mouse and Keyboard Interface for Microcontrollers.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
64 x 44mm.
|
 |
ATtiny816 Development/Breakout Board PCB [24110181]
The PCB for the ATtiny816 Breakout and Development Board with Capacitive Touch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 99mm.
|
 |
Isolated Serial Link PCB [24107181]
The PCB for the Zero-Risk Serial Link.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
72.5 x 74mm.
|
 |
Extremely Sensitive Magnetometer PCB [04101011]
The PCB for the Incredibly Sensitive Magnetometer described in the December 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
223.5 x 70mm.
|
 |
Useless Box PCB [08111181]
The PCB for the Useless Box described in the December 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99.5 x 66.5mm.
|
 |
Four-channel High-current DC Fan and Pump Controller PCB [05108181]
The PCB for the Four-channel DC Fan/Pump Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
68 x 35mm.
|
 |
Stackable LED Christmas Tree PCB [16107181]
Printed circuit board for building the Expandable LED Christmas Tree.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
99 x 97mm.
Multiple PCBs can be stacked to make a bigger tree. There are discounts if you order many boards.
The price breaks are at four ($18 total), 18 ($72), 31 ($120) and 38 ($145).
|
 |
USB Digital and SPI Interface PCB [16107182]
USB Digital Interface Module PCB, as used to drive the Expandable LED Christmas Tree.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
56 x 29mm.
|
 |
Tinnitus/Insomnia Killer PCB (Jaycar version) [01110181]
PCB for the Tinnitus and Insomnia Killer project. Made to fit into the Jaycar case.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
64 x 86mm.
|
 |
Tinnitus/Insomnia Killer PCB (Altronics version) [01110182]
PCB for the Tinnitus and Insomnia Killer project. Made to fit into the Altronics case.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
59 x 86mm.
|
|
Tinnitus/Insomnia Killer PCB (Jaycar version, manufacturing fault) [01110181]
PCB for the Tinnitus and Insomnia Killer project. Made to fit into the Jaycar case. These PCBs were printed with exposed copper. They will still work with the Tinnitus/Insomnia Killer project, but have some tracks partly exposed, which could lead to shorts if soldered incorrectly. Therefore this PCBs will be sold at a reduced price.
A bit of aerosol conformal coating or a solder mask touch up pen can be used to protect the exposed pads.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
64 x 86mm.
|
 |
GPS-synched Frequency Reference PCB [04107181]
The PCB for the GPS-synched Frequency Reference design published in the October and November 2018 issues.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
120 x 55mm.
|
|
DCC Decoder Programmer PCB plus stackable headers [09107181]
The PCB for the DCC Programmer project, plus a set of four stackable Arduino headers to suit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
69 x 54mm.
|
 |
Opto-Isolated Relay PCB plus two extension boards [10107181]
The PCB for the Opto-isolated Mains Relay project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
100 x 62mm. Also included: two small extension PCBs, 38 x 10.5mm each.
|
 |
Steam Train Whistle / Diesel Horn PCB [09106181]
The PCB for the Steam Train Whistle / Diesel Horn Sound Effects project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 48mm.
|
 |
Super Digital Sound Effects PCB [01107181]
The PCB for the Super Digital Sound Effects (SFX) Module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
55 x 23.5mm.
|
 |
Brainwave Monitor (EEG) PCB [25107181]
The PCB for the Brainwave Monitor / Electroencephalogram project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 84mm.
|
 |
Watchdog Door Alarm PCB [03107181]
The PCB for the Personal Door Alarm project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
40.5 x 93mm.
|
 |
Raspberry Pi 2.8-inch Touchscreen Display Adaptor PCB [24108181]
Raspberry Pi Display Adaptor PCB, as used in the Tide Chart / Info Screen project in the July 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
56.5 x 87.5mm.
|
 |
Recurring Event Reminder PCB [19107181]
PCB for the Recurring Event Reminder.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
38.5 x 62.5mm.
|
 |
800W+ Uninterruptible Power Supply control shield PCB [11106181]
PCB for the LiFePO4-based UPS Arduino control shield.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
68.5 x 54mm.
|
 |
USB Flexitimer PCB [19106181]
PCB for the USB Flexitimer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 58.5mm.
|
 |
Wide-range digital LC Meter PCB with stackable headers [04106181]
PCB for the Low-drift, Wide-range LC Meter
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Included with the PCB are the 10-pin, two 8-pin and 6-pin stackable headers.
68.5 x 53.5mm.
|
|
Wide-range digital LC Meter PCB [04106181]
PCB for the Low-drift, Wide-range LC Meter
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
If you want the PCB with stackable headers, check Cat SC4618 (www.siliconchip.com.au/Shop/8/4618).
68.5 x 53.5mm.
|
 |
Temperature Switch Mk2 PCB [05105181]
PCB for the Temperature Switch Mk2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 58.5mm.
|
 |
Deluxe Frequency Switch PCB [05104181]
PCB for the Multi-use Frequency Switch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 58.5mm.
|
 |
USB Port Protector PCB [07105181]
PCB for the USB Port Protector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
32.5 x 19mm.
|
 |
2 x 12V Battery Balancer PCB [14106181]
PCB for the 12V Battery Balancer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
31.5 x 34.5mm.
|
 |
Thermopile-based Heater Controller PCB [10104181]
PCB for the Infrared Sensing Heater Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
103 x 81.5mm.
|
 |
Triac-based Full Wave 230V Universal Motor Speed Controller PCB [10102181]
PCB for the Full-wave 230VAC Universal Motor Speed Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
103 x 81.5mm.
|
 |
AM Radio Transmitter PCB (RevB) [06101181]
PCB for the AM Radio Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57.5mm.
This version has a slight error which requires one track to be cut and two pads to be bridged - see Notes & Errata, July 2018. Because of this, the price has been reduced.
|
|
AM Radio Transmitter PCB (RevD) [06101181]
PCB for the AM Radio Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57.5mm.
|
 |
Vintage TV Analog Audio/Video Modulator PCB [02104181]
PCB for the Vintage TV Analog Audio/Video Modulator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
100 x 88mm.
|
 |
WiFi Water Tank Level Meter shield PCB with stackable headers [21110171]
PCB for the Solar Powered WiFi Water Tank Level Meter and Weather Station shield.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Included with the PCB are two 6-pin and two 8-pin stackable headers.
68.5 x 53.5mm.
|
 |
10-LED Bargraph PCB [04101181]
PCB for the Versatile Dot/Bar 10-LED Bargraph (main board) from the February 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
58.5mm x 122mm.
|
 |
10-LED Bargraph Signal Processing PCB [04101182]
Signal Processing (VU/PPM) PCB for the Versatile Dot/Bar 10-LED Bargraph from the February 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
58.5mm x 81mm.
|
 |
Theremin PCB [23112171]
PCB for the discrete Theremin design published in the January 2018 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
226mm x 87mm.
|
 |
High Power DC Fan Speed Controller PCB [05111171]
PCB for the Proportional High Power DC Fan Speed Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
49.5mm x 30.5mm.
|
 |
Super-7 AM Radio PCB [06111171]
PCB for the Super-7 Superhet AM Radio.
Double-sided PCB with black solder mask, plated through holes, solder mask and silkscreen overlay.
314 x 143mm.
|
 |
6GHz+ Touchscreen Frequency Counter PCB [04110171]
Main PCB for the 6GHz+ Touchscreen Frequency Counter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
This does not include the Micromite Plus Explore 100 PCB which is available separately, or as part of a short form kit for that project.
134 x 51.5mm.
|
 |
Kelvin the Cricket PCB [08109171]
PCB for Kelvin the Temperature-Sensitive Cricket.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
155 x 51mm.
|
 |
3-Way Adjustable Stereo Active Crossover PCB [01108171 RevD]
PCB for the 3-Way Active Crossover.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Note: there is an error on this board which affects its use with a centre-tapped transformer. See notes & errata in the May 2019 issue.
284 x 77.5mm.
|
|
3-Way Adjustable Stereo Active Crossover prototype PCB [01108171 RevC]
PCB for the 3-Way Active Crossover.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Two errors have been fixed on this board with track cuts. A note will be included indicating their locations. As a result, the price has been reduced.
284 x 77.5mm.
|
|
3-Way Adjustable Stereo Active Crossover PCB [01108171 RevE]
PCB for the 3-Way Active Crossover.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
284 x 77.5mm.
|
 |
Deluxe Touchscreen eFuse PCB [18106171]
PCB for the Deluxe Touchscreen eFuse.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
132 x 85mm.
Please note: the BUK7909-75AIE SenseFETs are no longer manufactured so check you can get those (or equivalents) before buying any parts for this project.
|
 |
Arduino Data Logger shield PCB with stackable headers [21107171]
PCB for the Arduino Data Logger shield.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Included with the PCB are two 6-pin and two 8-pin stackable headers.
68.5 x 53.5mm.
|
|
Arduino Data Logger shield PCB [21107171]
PCB for the Arduino Data Logger shield.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
68.5 x 53.5mm.
|
 |
Micromite LCD BackPack PCB [2.8-inch version) [07102122]
PCB for the 2.8-inch version of the Micromite LCD BackPack.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86 x 49.5mm.
|
 |
Set of four PCBs for the Battery-operated Valve Radio Mains Power Supply [18108171-4]
Four PCBs for the project titled "A power supply for battery-operated valve radios" from the August 2017 issue.
Each is a double-sided PCB with plated through holes, solder mask and silkscreen overlay. This set includes the following:
- Main PCB: green, coded 18108171, 55 x 110mm.
- Transformer PCB: green, coded 18108172, 110 x 33mm.
- Front panel PCB: black, coded 18108173, 122 x 33mm.
- Rear panel PCB: black, coded 18108174, 122 x 33mm.
Note: four resistors have been mis-labelled on the first batch of PCBs. This will be corrected in later batches. Please refer to the PCB overlay in the magazine for the correct values.
|
 |
RapidBrake PCB [05105171]
PCB for the RapidBrake Emergency Stop Signalling project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
107 x 58.5mm.
|
 |
10-Octave Stereo Graphic Equaliser PCB [01105171]
PCB for the High-performance 10-Octave Stereo Graphic Equaliser.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
199 x 76mm.
|
 |
New Marine Ultrasonic Anti-Fouling Unit PCB [04104171]
PCB for the New Marine Ultrasonic Antifouling Unit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
159 x 110.5mm.
|
 |
1000:1 6GHz+ Prescaler PCB [04112162]
PCB for the High Performance 1000-to-1 6GHz+ RF Prescaler.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89 x 53.5mm.
|
 |
Microbridge PCB [24104171]
PCB for the Microbridge.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 22.5mm.
|
 |
Micromite LCD BackPack V2 PCB [07104171]
PCB of the Micromite LCD BackPack V2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86 x 50mm.
|
 |
New Spring Reverberation Unit PCB [01104171]
PCB for the Spring Reverberation Unit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
142mm x 66mm.
|
 |
Electronic Fuse PCB [04102171]
PCB for the eFuse.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
73.5mm x 47mm.
|
 |
All-new Swimming Pool Lap Counter PCB [19102171]
PCB for the Bright LED Pool Lap Counter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
131 x 86.5mm.
|
 |
Stationmaster PWM train controller PCBs [09103171/2]
PCBs for the Stationmaster.
Set of two double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
The main PCB is 143.5 x 50.5mm and coded 09103171 while the hand controller PCB is 98 x 35.5mm and is coded 09103172.
|
 |
New SC200 Audio Amplifier PCB [01108161]
PCB for the article "Build the SC200... a new, high performance amplifier module".
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
For the power supply, you can use the Ultra-LD Power Supply PCB [01109911]: http://www.siliconchip.com.au/Shop/8/716
117 x 84mm.
|
 |
GPS-synchronised Analog Clock Driver PCB [04202171]
PCB for the GPS-synchronised Analog Clock Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay, 140 x 61.5mm.
This project is now obsolete. It has been replaced with the new version from September 2022 - see https://siliconchip.au/Shop/?article=15466
|
 |
Ultra-low-voltage Versatile LED Flasher PCB [16110161]
PCB for the Ultra Low Voltage Mini LED Flasher.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
15 x 19mm.
|
 |
High Power DC Motor Speed Control main PCB [11112161]
Main (Controller) PCB for the project entitled "Our biggest-ever DC speed controller: 12 to 60V at up to 40A".
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
107 x 81mm.
|
 |
High Power DC Motor Speed Control Mosfet PCB [11112162]
Mosfet PCB for the project entitled "Our biggest-ever DC speed controller: 12 to 60V at up to 40A".
Made with double-thickness (70µm) copper to handle the high currents.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
111 x 85mm.
|
 |
Automotive Sensor Modifier PCB [05111161]
PCB for the Automotive Sensor Modifier (Voltage Interceptor).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 58.5mm.
|
 |
Touchscreen Voltage/Current Reference PCB [04110161]
PCB for the Voltage/Current Reference with Touchscreen.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
140 x 85mm.
|
 |
50A Battery Charger Controller PCB [11111161]
PCB for the 50A Battery Charger Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 53.5mm.
|
 |
Passive Phono To Line Input Converter PCB [01111161]
PCB for the Inverse RIAA Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Snaps apart into two separate sections, both of which can be used to build the complete circuit. One uses SMD resistors/capacitors, the other through-hole types.
53.5 x 40.5mm.
|
 |
Micromite Plus LCD BackPack PCB [07110161]
PCB for the Micromite Plus LCD BackPack.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86 x 49.5mm.
|
 |
Mosquito Lure PCB [25110161]
PCB for the Male Mosquito Lure.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
78.5 x 44.5mm.
|
 |
Micropower LED Flasher PCB [16109161]
PCB for the Micropower LED Flasher (larger version).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
45 x 47mm.
|
 |
Mini Micropower LED Flasher PCB [16109162]
PCB for the Micropower LED Flasher (smaller version).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
36.2 x 12.7mm.
|
 |
Micromite Plus Explore 100 PCB [07109161 RevC]
PCB for the Micromite Plus Explore 100 computer.
Four-layer PCB with plated through holes, solder mask and silkscreen overlay.
135 x 85mm.
|
 |
Touchscreen Appliance Energy Meter PCB [04116061 RevI]
Main PCB for the Touchscreen-controlled Energy Meter. A Micromite LCD BackPack kit is also required.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
This revised version uses an ACS718 isolated current shunt IC rather than the ACS712, which had an insufficient Reinforced Voltage Rating for double-insulated use. The only other substitution required is to delete one 100nF 3216/1206 SMD capacitor and add one 1nF 3216/1206 SMD capacitor. See the December 2016 issue for further details on thse changes.
132 x 85mm.
|
 |
Currawong 2 x 10W Stereo Valve Amplifier main PCB [01111141]
Main PCB for the Currawong Valve Amplifier.
2mm thick, double-sided PCB with plated through holes and plated/unplated slots, solder mask and silkscreen overlay.
272 x 255mm.
|
 |
Currawong Remote Control PCB [01111144]
PCB for the Currawong Stereo Valve Amplifier remote control option.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 50mm.
|
 |
Cyclic Timer / Mains Period Timer PCBs [10108161/2]
PCBs for the two 230VAC Mains Timers. Sold as a pair.
Each is a double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Main PCB: 86 x 78mm, coded 10108161.
Control PCB: 84 x 35.5mm, coded 10108162.
|
 |
Automotive Fault Detector PCB [05109161]
PCB for the 4-input Automotive Fault Detector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89 x 53.5mm.
|
 |
Compact 8-Digit Frequency Meter PCB [04105161]
PCB for the Compact 8-Digit Auto-Ranging Frequency Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
121 x 58.5mm.
|
 |
Micromite Plus Explore 64 PCB [07108161]
PCB for the Micromite Plus Explore 64 module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
72 x 27mm.
|
 |
Universal Temperature Alarm PCB [03105161]
PCB for the Universal -33°C to 125°C Temperature Alarm.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 47mm.
|
|
Universal Temperature Alarm Prototype PCB [03105161 RevA]
Prototype PCB for the Universal -33°C to 125°C Temperature Alarm.
The only difference between this and the final version is that the 3.5mm socket "ring" connector is wired to ground, meaning you must use a stereo plug with the ring left disconnected. It has been discounted as a result.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 47mm.
|
 |
Brownout Protector PCB [10107161]
PCB for the Brownout Protector for Induction Motors.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 85mm.
|
 |
Stereo LED Audio Level Meter / VU Meter PCB [01104161]
PCB for the 100dB Stereo LED Audio Level/VU Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
177 x 76mm.
|
 |
Hotel Safe Alarm PCB [03106161]
PCB for the Hotel Safe Alarm.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
61 x 47mm.
|
 |
230/115VAC, 50/60Hz Precision Turntable Motor Driver PCB [04104161]
PCB for the Precision Turntable Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
84.5 x 112mm.
|
 |
4-input Temperature Sensor PCB for the Raspberry Pi [24104161]
A PCB for the Raspberry Pi Temperature Sensor Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
31 x 33.5mm.
|
 |
Arduino Multifunction Meter (MFM) PCBs [04116011/2]
PCBs for the Arduino Multifunction 24-bit Measuring Shield. Both the main shield board and RF Head PCBs are included.
They're both double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
The main board is coded 04116011 and measures 96.5 x 84mm.
The RF Head board is coded 04116012 and measures 42 x 41mm.
Note: the RF Head board has been revised to fix a short circuit and missing trimpot pad holes.
|
 |
Microwave Leakage Detector PCB [04103161]
PCB for the Microwave Oven Leakage Detector.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
64 x 32mm.
|
 |
Fridge/Freezer Alarm PCB [03104161]
PCB for the Fridge Door Alarm.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
30.5 x 65mm.
|
 |
Battery Pack Cell Balancer PCB [11111151]
PCB for the Battery Pack Cell Balancer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
69 x 35.5mm.
Note: for correct operation please replace D5 with a 0805 zero ohm jumper.
|
 |
Solar MPPT Charger & Lighting Controller PCB [16101161]
PCB for the MPPT Solar Charger and Lighting Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
141 x 112mm.
|
 |
QuickBrake/Delta Throttle Timer PCB [05102161]
PCB for the QuickBrake. Can also be used to build the Delta Throttle Timer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
189 x 73mm.
|
 |
Micromite LCD BackPack PCB [2.4-inch version) [07102121]
PCB for the 2.4-inch version of the Micromite LCD BackPack.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 43mm.
|
 |
PCB for the Digitally-controlled Audio Preamplifier (Circuit Notebook)
A PCB for the project described in Circuit Notebook, February 2016, "Digitally-controlled audio preamplifier with four stereo inputs".
Please note that as this is a Circuit Notebook item and not a project article, we can't provide any additional support beyond supplying the PCB, microcontroller firmware and the circuit description as published. You will have to figure out where to source the components, assembly and debugging by yourself.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
84 x 65mm.
|
 |
Stereo Valve Preamplifier PCB [01101161]
PCB for the High-Performance Stereo Valve Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
170 x 102mm.
|
 |
High Visibility 6-Digit LED GPS Clock PCB [19110151]
PCB for the GPS-enabled Six Digit LED Clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
303 x 70mm.
|
 |
White LED Turntable Strobe PCB [04101161]
PCB for the White LED Strobe for Turntables.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 31mm.
|
 |
Speech Timer PCB [19111151]
PCB for the Speech Timer for Contests and Debates.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
163 x 102mm.
Please note: there is a minor error on the RevB PCB which results in Q9's middle pin not being connected. Also, the labels for Q9 and Q10 may be swapped on the PCB. Make sure that Q9 and Q10 are fitted in the locations shown in the magazine. Check if the track for Q9's central pad is missing and if so, bend Q9's central lead over and solder it to the corresponding middle pad for Q10.
|
 |
Fingerprint Scanner PCBs [03109151/2]
PCBs for the Fingerprint Access Controller.
Includes both the main board and pushbutton board.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
The main board is coded 03109151 and measures 114.5 x 64mm. The switch board is coded 03109152 and measures 63.5 x 14mm.
|
|
Fingerprint Scanner Prototype PCBs [03109151/2]
PCBs for the Fingerprint Access Controller.
Includes both the main board and pushbutton board.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
The main board is coded 03109151 and measures 114.5 x 64mm. The switch board is coded 03109152 and measures 63.5 x 14mm.
Note: the only difference between this board and the final board is that the DC connector holes are too small and will need to be drilled out. As a result, we have discounted it.
|
 |
Universal Speaker Protector Mk3 PCB [01110151 RevC]
PCB for the revised Universal Loudspeaker Protector module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
88 x 80mm.
RevC fixes the error in the wiring of the SMD bridge rectifier pads.
|
 |
Arduino USB Electrocardiogram PCB [07108151 RevB]
PCB for the Arduino-based USB ECG project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
93 x 53.5mm.
|
|
Ultra-LD Mk.4 Amplifier prototype PCB [01107151 RevB]
Prototype PCB for the Ultra-LD Mk.4 200W Power Amplifier.
This board has been discounted although it's almost identical to the final PCB. You MUST cut the track completely from D6 which runs to the far end of the adjacent 100kΩ resistor. Once the components have been fitted, add a tiny length of wire to join the disconnected pad of D6 to the nearest pad of the adjacent 100kΩ resistor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
135 x 93mm.
|
 |
9-Channel Infrared Remote Control PCB [15108151]
PCB for the 9-Channel Infrared Remote Control Receiver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
87 x 132mm.
|
 |
Mini 12V USB Power Supply with Low-Battery Cut-out PCB [18107151/18107152]
PCB for the Mini 12V USB Power Supply with Low Battery Cutout. Can also be used to generate other voltages (step-down).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
16 x 51mm.
This board is coded 18107152 but can also be used instead of the one coded 18107151, as it has exactly the same function.
Just don't fit any parts to the back side of the board if you don't need the low-battery cut-out function. Make sure that those pads can't short against anything during testing.
|
 |
Low-Cost, Accurate Voltage/Resistance/Current Reference PCB [04108151]
Voltage/Resistance/Current Reference circuit board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
44.5 x 23mm.
|
 |
Driveway Monitor detector/transmitter PCB [15105151]
Main detector/transmitter PCB for the Driveway Monitor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Routed to shape.
104 x 78mm.
|
 |
Driveway Monitor receiver PCB [15105152]
Receiver PCB for the Driveway Monitor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Routed to shape.
79 x 47mm.
|
 |
LED Party Strobe PCB [16101141]
PCB for the LED Party Strobe.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
95 x 78mm.
Note that this board suits a variety of projects. In addition to the LED Strobe, it can also be used to build a Hot Wire Cutter or a small DC motor speed controller. For these applications, some sections of the board are designed to be snapped or cut off and it will then fit into a UB5 jiffy box. It also has provision to use a DC socket to supply power rather than a terminal block.
|
 |
Signal Injector and Tracer PCB [04106151]
PCB for the Signal Injector & Tracer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
63.5 x 85.5mm.
|
 |
Signal Injector and Tracer shield PCB [04106153]
Shield PCB for the Signal Injector & Tracer.
Single-sided PCB with plated through hole and solder mask.
62 x 63mm.
|
 |
Signal Tracer RF Probe PCB [04106152]
RF Probe PCB for the Signal Injector and Tracer (or other signal tracers).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
45.5 x 11.5mm.
|
 |
Bad Vibes Infrasound Snooper / Low Frequency Distortion Analyser PCB [04104151]
PCB for the Infrasonic Snooper or Low Frequency Distortion Analyser.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 60.5mm.
|
 |
Champion/Pre-champion PCB [01109121/01109122]
PCB for the Champion and Pre-champion low power audio amplifier.
Boards come joined; they can be built as a single unit or cut apart with a hacksaw.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
100 x 41mm.
|
 |
Appliance Earth Leakage Tester PCBs [04203151/2]
PCBs for the Earth Leakage Tester.
The main board is a double-sided PCB with plated through holes, solder mask and silkscreen overlay. It is coded 04203151 and meaures 86.5 x 141mm.
The smaller blank barrier PCB is also included - coded 04203152 and measuring 88.5 x 26mm.
|
 |
Balanced Attenuator PCB [04105151]
PCB for the Balanced Input Attenuator for Audio Analysers and Scopes.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Note: power supply PCB also required (code 18105151).
160 x 80mm.
|
 |
4-Output Universal Regulator PCB [18105151]
PCB for the Universal Four-Output Adjustable Regulator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Used in the Balanced Input Attenuator project but can also be used in many other projects, including the Studio Series Stereo Preamplifier (replacing the board coded 01109052).
76 x 46mm.
|
 |
Appliance Insulation Tester PCB [04103151]
PCB for the Appliance Insulation Tester.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
86 x 133.5mm.
|
 |
Nixie Clock Mk2 PCBs [19102151/2]
PCBs for the Nixie Clock Mk2.
Both double-sided PCB with plated through holes, solder masks and silkscreen overlays.
The lower board is 19102151 and meaures 144 x 64mm. The upper board is coded 19102152 and measures 144 x 59mm. Sold as a set.
|
 |
Spark Energy Meter PCBs [05101151/2]
PCBs for the Spark Energy Meter.
Includes the main board (05101151) and the Zener diode board (05101152). The calibrator board is available as a separate item.
These boards were listed with codes 04101151 and 04101152 in some places.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
110.5 x 85mm each.
|
 |
Spark Energy Meter calibrator PCB [05101153]
Calibrator PCB for the Spark Energy Meter. Can also be used as a simple 5V/12V DC motor speed controller or lamp dimmer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
61 x 47mm.
|
 |
Isolated High-Voltage Probe PCB [04108141]
PCB for the Isolating High Voltage Probe.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
70 x 122mm.
|
 |
Multispark CDI PCB [05112141]
PCB for the High-Energy Multispark Capacitor Discharge Ignition for Performance Vehicles.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
110.5 x 85mm.
|
 |
44-pin Micromite PCB [24108141]
PCB for the 44-pin Micromite.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
68 x 22mm.
|
 |
Time Domain Reflectometer (TDR) Dongle PCB [04112141]
PCB for the TDR Dongle.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
82 x 41mm.
|
 |
48V Dual Phantom Power Supply PCB [18112141]
PCB for the 48V Dual Phantom Power Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
113 x 56mm.
|
 |
Remote Switching Programmable Mains Timer PCB [19112141]
PCB for the Programmable Mains Timer With Remote Switching.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 76mm.
|
 |
One-Chip 2 x 5W Mini Stereo Amplifier PCB [01109141]
PCB for the 2 x 5W Mini Stereo Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Note that the SMD parts are available separately.
63.5 x 39mm.
|
 |
Car LED Courtesy Light Delay PCB [05109141/15109141]
PCB for the LED Courtesy Light Delay for Cars.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
71 x 47mm.
|
 |
Passive Direct Injection (DI) Box PCB [23109141]
PCB for the Passive Direct Injection Box.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
106 x 23mm.
|
 |
Opto-Theremin PCB [23108141]
Main PCB for the Opto-Theremin.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
147 x 85mm.
|
 |
Proximity Sensor PCB for the Opto-Theremin [23108142]
Proximity Sensor PCB, as used in the Opto-Theremin.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
61 x 47mm.
|
 |
Dual-Channel Audio Delay / Stereo Echo & Reverb / Digital Effects Processor PCB [01110131]
PCB for the Stereo Audio Delay/DSP project. Can be used to build the following projects:
- Stereo Audio Delay
- Stereo Echo & Reverberation Unit
- Digital Effects Processor for Guitars/Musical Instruments
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
148 x 80mm.
|
 |
Wideband Active Differential Scope Probe PCBs [04107141/2]
Pair of PCBs for the Wideband Active Differential Oscilloscope Probe.
Two double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
103 x 26mm each.
|
 |
Mini-D Class-D amplifier PCB [01110141]
PCB for the Mini-D Class-D mono/stereo amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
46 x 85mm.
|
 |
Nirvana Valve Sound Simulator PCB [01106141]
Main PCB for the "Nirvana" Valve Sound Simulator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
130 x 101mm.
|
 |
TempMaster Mk3 PCB [21108141]
PCB for the TempMaster Thermostat Mk3.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
81 x 105mm.
|
 |
Threshold Voltage Switch PCB [99106141]
PCB for the Threshold Voltage Switch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
107.5 x 60.5mm.
|
 |
ASCII Video Terminal PCB [24107141]
PCB for the ASCII Video Terminal project, which accompanies the Micromite.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89 x 51mm.
|
 |
Touch-screen Audio Recorder PCB [01105141]
PCB for the Touchscreen Audio Recorder & Playback unit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Edges are routed to fit in the specified handheld case.
106 x 74mm.
|
 |
2.5GHz 12-Digit Frequency Counter Main PCB [04111121]
Main PCB for the High-Resolution 2.5GHz 12-Digit Frequency Counter project.
(May also be referred to as a Frequency Meter).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
225 x 174mm.
|
 |
2.5GHz 12-Digit Frequency Counter Display PCB [04111122]
Display PCB for the High-Resolution 2.5GHz 12-Digit Frequency Counter project.
(May also be referred to as a Frequency Meter).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
200 x 50mm.
|
 |
2.5GHz 12-Digit Frequency Counter Add-on PCB [04106141a/b]
Long Gating Times add-on board for the High-Resolution 2.5GHz 12-Digit Frequency Counter project.
(May also be referred to as a Frequency Meter).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
169 x 44.5mm. Designed to be snapped or cut apart into two sections.
|
 |
40V/5A Hybrid Switchmode/Linear Bench Supply PCB [18104141]
PCB for the 100W Hybrid Bench Supply.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
198 x 95mm.
|
 |
RGB LED Strip Driver PCB [16105141]
PCB for the Phantasmagorical RGB LED Strip Driver/Controller PCB.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
82 x 55mm.
|
 |
Deluxe 230VAC Fan Speed Controller PCB [10104141]
PCB for the 230VAC Linear Fan Speed Control.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
93 x 79mm.
|
 |
USB/RS-232C Serial Interface PCB [07103141]
PCB for the USB/RS232C Interface.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 46mm.
|
 |
Rubidium Frequency Standard Breakout Board PCB [04105141]
PCB for the Rubidium Time and Frequency Standard Breakout Board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
We have also made provision for a rear-facing DC socket, so that the DC plug can pass through a hole drilled in the case.
102 x 38mm.
|
 |
Precision 10V DC Reference Mk2 PCB [04104141]
PCB for the Precision 10V Reference Mk2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
63.5 x 53.5mm.
|
 |
NiMH/Nicad Burp Charger PCB [14103141]
PCB for the Nicad/NiMH Battery Burp Charger.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
105.5 x 87mm.
|
 |
230V/10A Universal Motor Speed Controller PCB [10102141]
PCB for the Super Smooth Motor Speed Controller. An updated version of one of our more popular projects.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
141 x 112mm.
|
|
230V/10A Universal Motor Speed Controller prototype PCB [10102141]
PCB for the Super Smooth Motor Speed Controller. An updated version of one of our more popular projects.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
141 x 112mm.
Please note: this PCB has a small error which requires a signal track cut and re-wired. As such, it has been discounted and a revised board is being stocked with this corrected. Purchasers get instructions to make the required changes.
|
 |
PortaPAL-D PCBs [01111131-3]
Set of PCBs for the PortaPAL-D. This includes the main mixer and power supervision board (01111131), microphone input board (01111132) and guitar/line input/output board (01111133).
Not included are the CLASSiC-D amplifier, speaker protector or DC/DC converter PCBs. Those are required to build the PortaPAL-D but are available separately.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
01111131 - 212 x 100mm
01111132 - 65 x 73mm
01111133 - 110 x 35mm
|
 |
Mini Regulator PCB (MiniReg) [18112111]
PCB for the Mini 1.3-22V Adjustable Regulator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
35 x 38mm.
|
 |
Bass Extender Mk2 PCB [01112131]
PCB for the Bass Extender Mk2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
148 x 80mm.
|
 |
Tiny Tim Power Supply PCB [18110131]
Power supply PCB for the Tiny Tim amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
100 x 75mm.
|
 |
Li'l Pulser Mk2 Revised PCB [09107134]
PCB for the Li'l Pulser Mk2 model train controller. Includes the refinements published in the January 2014 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
129.5 x 100mm.
|
 |
Hifi Stereo Headphone Amplifier PCB [01309111]
PCB for the Hifi Stereo Headphone Amplifier.
PCB with plated through holes, solder mask and silkscreen overlay.
198 x 98mm.
|
 |
Bellbird PCB [08112131]
PCB for the Bellbird.
Double-sided PCB with plated through holes, solder mask (green) and silkscreen overlay. Board is supplied cut to shape.
91.5 x 73mm.
|
 |
GPS Tracker PCB [05112131]
PCB for the GPS Tracker/Logger.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
137 x 69mm.
|
 |
SiDRADIO main PCB [06109131]
Main PCB for the SiDRADIO self-contained SDR.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Includes cut-out for dongle.
157 x 198mm.
|
 |
Automatic Car Headlight Controller PCB [03111131]
PCB for the Automatic Car Headlight Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
98 x 53mm.
|
 |
Speedo Corrector Mk3 PCB [05109131]
PCB for the Speedo Correct Mk3.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
94 x 82.5mm.
|
 |
Battery LifeSaver PCB [11108131]
PCB for the Battery LifeSaver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
34 x 18.5mm.
|
 |
PC Birdies PCB [08104131]
PCB for the PC Birdies.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
62 x 48mm.
|
 |
iPod Charger PCB [14108131]
PCB for the iPod Charger Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
60 x 18mm.
|
 |
RF Probe PCB [04107131]
PCB for the RF Probe.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
61 x 29mm.
|
 |
1.5kW Induction Motor Speed Controller PCB [10105122]
PCB for the 1.5kW Induction Motor Speed Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Includes routed holes (unplated) for access to heatsink mounting screws.
This is the updated version of the PCB which addresses the reliability problems that some constructors experienced. Specifically, some high-current/high-voltage tracks were routed away from the control portion of the IGBT hybrid module to prevent interference. See the article in the December 2012 issue (link below) for more details.
200 x 125mm.
|
 |
Infrared to UHF Converter PCB [15107131]
PCB for the Infrared Remote Control to UHF Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
20.5 x 47mm. Fits inside an existing infrared remote control so that it can transmit RF on 433MHz.
|
 |
UHF to Infrared Converter PCB [15107132]
PCB for the UHF to Infrared Remote Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 47mm. Has corner cut-outs to fit into jiffy box. Normally used in combination with the IR-to-UHF Converter.
|
 |
USB Port Checker PCB [24107131]
PCB for the USB Port Checker.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
44.5 x 16.5mm.
|
 |
Revised 10-Channel Remote Control Receiver PCB [15106133]
Updated PCB for the 10 Channel Remote Control Receiver. Allows simultaneous use of IR and UHF receivers. Otherwise identical to the original version (15106131).
Remember to use the updated software with this board (1510613B).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
123 x 61mm.
|
 |
LF-HF Up-Converter PCB [07106131]
PCB for the LF-HF Up-Converter for VHF/UHF SDRs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
80 x 51mm.
|
 |
10-Channel Remote Control Receiver PCB [15106131]
PCB for the 10 Channel Remote Control Receiver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
123 x 61mm.
|
 |
IR to 433MHz UHF Transceiver PCB [15106132]
PCB for the IR to 433MHz UHF Transceiver
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
79 x 47mm.
|
 |
"Lump In Coax" Portable Mixer PCB [01106131]
PCB for the battery-powered "Lump In Coax" mixer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design]. Board is supplied with corner cut-outs already routed out.
110 x 85mm.
|
 |
CLASSiC-D DC/DC Converter PCB [11104131]
PCB for the CLASSiC-D 12V to ±35V DC/DC Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
110 x 85mm.
|
 |
Do Not Disturb PCB [12104131]
PCB for the Do Not Disturb telephone off-hook timer project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Board is routed to shape. 79 x 46mm.
|
 |
CLASSiC DAC main PCB [01102131]
Main PCB for the High-Performance CLASSiC DAC.
Please note that the SD card socket that this original PCB was designed to accept is no longer available. This board has been discounted as a result. It will still work well if you don't plan to use the SD card functions.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
157 x 198mm.
|
|
CLASSiC DAC revised main PCB [01102134]
The main PCB for the High-Performance CLASSiC DAC.
This board is the version modified to use the Altronics P5722 SD card socket. We have tried to mount it so that the front panel slot will line up, but it's possible that you will have to file the slot larger to allow the card to be pushed in and pulled out smoothly.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
157 x 198mm.
|
 |
LED Ladybird PCB [08103131]
PCB for the LED Ladybird/Lady Beetle.
Double-sided PCB with plated through holes, black solder mask and white silkscreen overlay.
Board is provided routed in the shape of a beetle. 32 x 42mm.
|
|
LED Ladybird prototype PCB [08103131]
PCB for the LED Ladybird/Lady Beetle.
Double-sided PCB with plated through holes, black solder mask and white silkscreen overlay.
This is a prototype version which requires one track to be cut (joining the anodes of LEDs1&2 to Vss) but otherwise is the same as the final version. It has been discounted to reflect the fact that it must be modified.
Board is provided routed in the shape of a beetle. 32 x 42mm.
|
 |
Deluxe GPS 1pps Timebase PCB [04104131]
PCB for the Deluxe USB GPS 1pps Timebase for Frequency Counters.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57mm.
|
 |
Automatic Points Controller PCB [JWM-0812/09103131]
PCB for the Automatic Points Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design). Top layer tracks mean you don't need to install any wire links on this board.
100 x 50mm. It's also supplied with two small sensor boards, 19 x 9mm each, coded 09103132.
"Frog" relay board available separately.
|
 |
"Frog" Relay PCB [09103133]
PCB for the "Frog" Relay, used for the Automatic Points Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
26 x 35.5mm.
|
 |
Capacitor Discharge PCB for Twin-Coil Points Motors [09203131]
PCB for the model railway Capacitor Discharge Unit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
69 x 41mm.
|
 |
AAA LED Torch Driver PCB [16102131]
PCB for the AAA LED Torch Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
10 x 42mm.
|
 |
Prechamp: 2-Transistor Preamplifier PCB [01107941]
PCB for the Prechamp: 2-Transistor Preamplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
46 x 36mm.
|
 |
Champ: Single Chip Audio Amplifier PCB [01102941]
PCB for the Champ: Single Chip Audio Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
46 x 26mm.
|
 |
Mk2 Seismograph with Tsunami Alarm PCB [21102131]
PCB for the Do-It-Yourself Seismograph (Mk.2) with Tsunami Alarm.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
122 x 57mm.
|
 |
Mobile Phone Loud Ringer PCB [12110121]
PCB for the Mobile Phone Extension Ringer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
63.5 x 86mm.
|
 |
Accurate GPS 1pps Timebase PCB [04103131]
PCB for the GPS-based 1pps Timebase for Frequency Counters.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
66 x 46mm.
|
 |
High Energy Electronic Ignition PCB [05110121]
PCB for the High Energy Electronic Ignition System.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
89 x 53mm.
|
 |
Garbage/Recycling Reminder PCB [19111121]
PCB for the Garbage and Recycling Reminder.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
79 x 46mm.
|
 |
USB Power Monitor PCB [04109121]
PCB for USB power monitor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
65 x 36mm.
|
 |
CLASSiC-D PCB [01108121]
Main PCB for the CLASSiC-D High-Power Switching Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Three 560pF MKT capacitors are also supplied with the board.
For the power supply use PCB 01109111 - www.siliconchip.com.au/Shop/8/716
Also has routed slots for air to circulate through the heatsink fins. 112 x 170mm.
|
 |
CLASSiC-D Speaker Protector PCB [01108122]
Speaker Protector PCB for the CLASSiC-D High-Power Switching Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
76 x 66mm.
|
 |
LED Musicolour PCB [16110121]
Main PCB for the LED Musicolour.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
103 x 118mm.
|
 |
DCC Reverse Loop Controller PCB [09110121]
PCB for the DCC Reversing Loop Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
74 x 48mm.
|
 |
Nick-Off! Proximity Alarm PCB [03110121]
PCB for the Nick-Off! Bad Cat Deterrent.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
50 x 50mm.
|
 |
Colour Maximite PCB [07109121]
Main PCB for the Colour Maximite.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
130 x 102mm.
|
 |
Barking Dog Blaster PCB [25108121]
PCB for the Barking Dog Blaster.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
106 x 61mm.
|
 |
USB Virtual Instrument Interface PCB [24109121]
PCB for the USB Virtual Instrument Interface ("Virtins").
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
160 x 109mm.
|
 |
Sound Effects Generator PCB [09109121]
PCB for the Digital Sound Effects Module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
59 x 28mm.
|
 |
Driveway Sentry Mk.2 PCB [03107121]
PCB for the Driveway Sentry MK.2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design, links replaced with top layer tracks].
140 x 84mm.
|
 |
Mains Timer PCB [10108121]
PCB for the Mains Time For Fans or Lights.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
60 x 76mm.
|
 |
High Current Adaptor For Scopes And DMMs PCB [04108121]
PCB for the High-Current Adaptor For Scopes & DMMs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
60 x 107mm.
|
 |
Wideband Oxygen Controller Mk.2 Display PCB [05106122]
Display board for the Wideband Oxygen Controller Mk.2. This can also be used for the Programmable Ignition System in place of the Hand Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
79 x 47.5mm.
|
 |
Wideband Oxygen Controller Mk.2 PCB [05106121]
Main PCB for the Wideband Oxygen Controller Mk.2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
149 x 75.5mm.
|
 |
Soft Starter For Power Tools PCB [10107121]
PCB for the Soft Starter for Power Tools.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
59 x 80.5mm.
|
 |
Capacitance Decade Box PCB [04106121]
PCB for the Capacitance Decade Box.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design]. PCB outline is routed to shape.
146 x 86mm.
|
 |
Crazy Cricket/Freaky Frog PCB [08109121]
PCB for the Crazy Cricket/Freaky Frog.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
30 x 65mm.
|
 |
Mix-It! 4 Channel Mixer PCB [01106121]
PCB for the Mix-It! Four Channel Mixer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design with top layer tracks replacing links].
198 x 60mm.
|
 |
PIC/AVR Programming Adaptor Board PCB [24105121]
Main PCB for the PIC/AVR Programming Adaptor Board.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
116 x 127mm.
|
 |
High Temperature Thermometer/Thermostat PCB [21105121]
PCB for the High Temperature Thermometer/Thermostat.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design with top layer track replacing link].
117 x 102mm.
|
 |
SemTest Upper PCB [04103122]
Upper board for the SemTest.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
202 x 122.5mm.
|
 |
SemTest Lower PCB [04103121]
Lower board for the SemTest.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
211 x 135mm.
|
 |
High Voltage Crowbar PCB [04105121]
High-Voltage SCR Crowbar board which can be used in the SemTest or in other situations to quickly discharge high-voltage capacitors.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
56 x 40.5mm.
|
 |
Preamp & Remote Volume Control PCB for the Ultra-LD Mk3 [01111111]
PCB for the Preamplifier & Remote Volume Control for the Ultra-LD Mk3 Amplifier. Can also be used to build the 20W Class-A amplifier (note: there are some slight differences in connectors).
PCB with plated through holes, solder mask and silkscreen overlay.
201 x 63mm.
|
 |
Soft Start Surge Suppressor PCB [10104121]
PCB for the SoftStarter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
56 x 76mm.
|
 |
Resistance Decade Box PCB [04104121]
PCB for the Resistance Decade Box.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design]. PCB outline is routed to shape.
146 x 86mm.
|
 |
Interplanetary Voice PCB [08102121]
PCB for the Interplanetary Voice.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
92 x 54mm.
|
 |
12/24V 3-Stage MPPT Solar Charger Rev.1 PCB [14102112]
PCB for the 12/24V 3-Stage MPPT Solar Charger Rev.1.
Improved version.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. PCB outline is routed to shape.
111 x 85mm.
|
|
12/24V 3-Stage MPPT Solar Charge Controller PCB [14102111]
PCB for the 12/24V 3-Stage MPPT Solar Charge Controller.
PCB with plated through holes, solder mask and silkscreen overlay.
This PCB is now superseded by the revised edition, 14102112, however it is still valid.
111 x 85mm.
|
 |
Crystal DAC PCB [01102121]
PCB for the Crystal DAC.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
94 x 110mm.
|
 |
MiniSwitcher PCB [18102121]
PCB for the 1.5A Switching Regulator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
49.5 x 34mm.
|
 |
Stereo Audio Compressor PCB [01201121]
PCB for the Stereo Audio Compressor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design with top layer tracks replacing links].
117 x 101mm.
|
 |
AM Radio PCB [06101121]
PCB for the AM Radio project.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay [single-sided design]. PCB outline is routed to shape plus routed mounting holes for tuning capacitor.
64 x 86mm.
|
 |
3-Input Audio Selector (Set of 2 PCBs) [01101121/2]
PCBs for the 3-Input Audio Selector.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay [single-sided designs]. Main PCB outline is routed to shape.
Sold as a set; 101 x 81mm and 84 x 38mm.
|
 |
Digital Audio Delay [01212111]
PCB for Digital Audio Delay.
PCB with plated through holes, solder mask and silkscreen overlay.
103 x 118mm.
|
 |
miniMaximite Microcomputer PCB [07111111]
PCB for the miniMaximite Computer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
78 x 38mm.
|
 |
Zener Diode Tester PCB [04111111]
PCB for the 2.2-100V Zener Diode Tester.
PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
61 x 107mm.
|
 |
Digital Spirit Level/Inclinometer or G-Force Meter PCB [04108111]
PCB for the Digital Spirit Level/Inclinometer. This same board is also used for the G-Force Meter project.
PCB with plated through holes, solder mask and silkscreen overlay [single-sided design].
100 x 44mm.
|
 |
Quizzical Quiz Game PCB [08110111]
PCB for the Quizzical Quiz Game.
PCB with plated through holes, solder mask and silkscreen overlay.
115 x 102mm.
|
 |
USB MIDI-Mate PCB [23110111]
PCB for the USB MIDI-Mate.
PCB with plated through holes, solder mask and silkscreen overlay.
117 x 102mm.
|
 |
Digital Lighting Controller LED Slave PCB [16110111]
PCB for the Digital Lighting Controller LED Slave.
PCB with plated through holes, solder mask and silkscreen overlay.
103 x 118mm.
|
 |
Speaker Protection and Muting Module PCB [01207071]
PCB for the Speaker Protection And Muting Module.
Suits the original version (July 2007) and updated version (October 2011). Can be used to build the 20W Class-A Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
112.5 x 80mm.
|
 |
Ultrasonic Water Tank Level Gauge PCB [04109111]
PCB for the Ultrasonic Water Tank Level Gauge.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
104 x 78.5mm.
|
 |
GPS Frequency Reference Display PCB [04103072]
Display PCB for the GPS-Based Frequency Reference.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design with links replaced by tracks on the top layer).
144 x 58mm.
|
 |
Revised GPS-Based Frequency Reference PCB [04103073]
Updated PCB for the updated GPS Frequency Reference.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design with links replaced by tracks on the top layer).
142 x 123mm.
Note: the Garmin GPS-15L module used in this project is no longer available. It has been superseded by the GPS-15xL which is a drop-in replacement with superior sensitivity.
|
 |
Upgrade PCB for the Ultra-LD Mk2 Amplifier [01209111]
PCB to upgrade the Ultra-LD Mk2 Amplifier to Mk3 performance.
PCB with plated through holes, solder mask and silkscreen overlay.
20.5 x 36.5mm.
|
 |
Electronic Stethoscope PCB [01108111]
PCB for the Electronic Stethoscope.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
65 x 86mm.
|
 |
Rudder Position Indicator PCB Set [20107111/2/3/4]
Set of 4 PCBs for the Rudder Position Indicator for Power Boats.
PCBs with plated through holes, solder mask and silkscreen overlay (single-sided designs with links replaced by top layer tracks).
98.5 x 68mm each.
|
 |
Portable Lightning Detector PCB [04107111]
PCB for the Portable Lightning Detector.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
65 x 86mm.
|
 |
VOX PCB [01207111]
PCB for the VOX Voice-Activated Relay.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
106 x 61mm.
|
 |
20A 12/24V DC Motor Speed Controller Mk2 PCB [11106111]
PCB for the 20A 12/24V DC Motor Speed Controller Mk2.
PCB with plated through holes, solder mask and silkscreen overlay.
106 x 60mm.
|
 |
USB Stereo Record/Playback PCB [07106111]
PCB for the USB Stereo Recording & Playback Interface.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 84mm.
|
 |
VersaTimer/Switch PCB [19106111]
PCB for the VersaTimer/Switch.
PCB with plated through holes, solder mask and silkscreen overlay.
103 x 78mm.
|
 |
USB Breakout Box PCB [04106111]
PCB for the USB Breakout Box.
PCB with plated through holes, solder mask and silkscreen overlay.
76 x 45mm.
|
 |
SportSync Audio Delay PCB [01105111]
PCB for the SportSync Audio Delay Module.
PCB with plated through holes, solder mask and silkscreen overlay.
118 x 104mm.
|
 |
100W DC-DC Converter PCB [11105111]
PCB for the 100W DC-DC Converter.
PCB with plated through holes, solder mask and silkscreen overlay.
111 x 85mm.
|
 |
Phone Line Polarity Checker PCB [12105111]
PCB for the Phone Line Polarity Checker.
PCB with plated through holes, solder mask and silkscreen overlay.
56.5 x 48.5mm.
|
 |
Maximite PCB [06103111]
PCB for the Maximite Microcomputer.
PCB with plated through holes, solder mask and silkscreen overlay.
124 x 69mm.
|
 |
Portable Stereo Headphone Amplifier PCB [01104111]
PCB for the Portable Stereo Headphone Amplifier.
PCB with plated through holes, solder mask and silkscreen overlay.
67 x 58.5mm.
|
 |
100V Speaker/Line Checker PCB [04104111]
PCB for the 100V Speaker & Line Checker.
PCB with plated through holes, solder mask and silkscreen overlay.
100 x 60mm.
|
 |
Projector Speed Controller PCB [13104111]
PCB for the Projector Speed Controller.
PCB with plated through holes, solder mask and silkscreen overlay.
62 x 47mm.
|
 |
20W Class-A Amplifier Power Supply PCB [01105074]
Power supply circuit board for the 20W Class A Amplifier.
This is the revised version with provision for chokes to reduce transformer buzz, as described in the April 2011 issue. However they can be replaced with wire links if they are not needed. Thus the board replaces the original which was coded 01105073 and was approximately the same size.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
157 x 73mm.
|
 |
12V 20-120W Solar Panel Simulator PCB [04103111]
PCB for the 12V 20-120W Solar Panel Simulator.
PCB with plated through holes, solder mask and silkscreen overlay.
99 x 76mm.
|
 |
Hearing Loop Receiver/Neck Loop Coupler PCB [01209101]
PCB for the Hearing Loop Receiver. Also suits the Neck Loop Coupler project (same PCB, different components).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
Note that this is the version to suit the Jaycar hand-held case.
68 x 86mm.
|
 |
LED Dazzler PCB [16102111]
PCB for the LED Dazzler.
PCB with plated through holes, solder mask and silkscreen overlay.
118 x 74mm.
|
 |
433MHz Locator PCB [06102111]
PCB for the 433MHz Locator.
PCB with plated through holes, solder mask and silkscreen overlay.
23.5 x 27mm.
|
 |
433MHz Sniffer PCB [06101111]
PCB for the 433MHz Sniffer.
PCB with plated through holes, solder mask and silkscreen overlay.
70 x 28mm.
|
 |
Cranial Electrical Stimulation Unit PCB [99101111]
PCB for the Cranial Electrical Stimulation (CES) Unit.
PCB with plated through holes, solder mask and silkscreen overlay.
118 x 102mm.
|
 |
Hearing Loop Signal Conditioner PCB [01101111]
PCB for the Hearing Loop Signal Conditioner.
PCB with plated through holes, solder mask and silkscreen overlay.
118 x 102mm.
|
 |
Hot Wire Cutter Controller PCB [18112101]
PCB for the Hot Wire Cutter with inbuilt Heat Controller.
Can also be used to build the 12V Speed Controller/Dimmer.
PCB with plated through holes, solder mask and silkscreen overlay.
77 x 50mm.
|
 |
Digital Lighting Controller Slave Unit PCB [16110102]
PCB for the Digital Lighting Controller Slave Unit.
PCB with plated through holes, solder mask and silkscreen overlay.
216 x 157.5mm.
|
 |
Hearing Loop Tester/Level Meter PCB [01111101]
PCB for the Hearing Loop Tester/Level Meter.
PCB with plated through holes, solder mask and silkscreen overlay.
65 x 86mm.
|
 |
Toslink To S/PDIF/Coax Converter PCB [01210102]
PCB for the Toslink to S/PDIF/Coax Converter.
PCB with plated through holes, solder mask and silkscreen overlay.
74 x 34.5mm.
|
 |
S/PDIF/Coax To Toslink Converter PCB [01210101]
PCB for the S/PDIF/Coax To Toslink Converter.
PCB with plated through holes, solder mask and silkscreen overlay. Note that a piece of wire needs to be soldered between the GND pin of the TOSLINK transmitter and the adjacent 100nF capacitor for it to work.
74 x 34.5mm.
|
 |
GPS Car/Boat Computer PCB [05101101]
GPS Car Computer circuit board. Can also be used to build the GPS Boat Computer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
124 x 43mm.
|
 |
High-Performance Microphone Preamplifier PCB [01109101]
The PCB for the High-Performance Mic Preamp.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
56 x 49.5mm
|
 |
Electrolytic Capacitor Reformer & Tester PCB [04108101]
PCB for the Electrolytic Capacitor Reformer and Tester.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
210 x 120mm.
|
 |
Remote-Controlled Digital Up/Down Timer PCB [19108101]
PCB for the Infrared Remote Up/Down Timer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
89.5 x 80mm.
|
 |
Intelligent 12V Fan Controller PCB [18107101]
The PCB for the Intelligent 12V Fan Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
100 x 80mm
|
 |
Lab-Standard 16-Bit Digital Potentiometer PCB [04107101]
The PCB for the 16-Bit Lab-Standard Digital Potentiometer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The wire links have been replaced with top-layer tracks.
184 x 99mm.
|
 |
Dual Tracking ±0-19V Power Supply PCB [04206101]
The PCB for the 2010 Dual Tracking Bench Supply.
Single-sided green PCB with solder mask and silkscreen overlay.
112 x 105mm.
|
 |
Dual Tracking ±0-19V Power Supply front panel PCB [04206102]
The front panel PCB for the 2010 Dual Tracking Bench Supply.
PCB with solder mask and silkscreen overlay.
97.5 x 58mm.
|
 |
Air Quality Monitor PCB [04306101]
The PCB for the Air-Quality Meter for Checking CO & CO₂ Levels.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
104 x 78mm
|
 |
Digital Insulation Meter PCB [04106101]
Main PCB for the Digital Insulation Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 84mm
|
 |
Digital Insulation Meter Power Supply PCB [04106102]
Power supply PCB for the Digital Insulation Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
70 x 51mm.
|
 |
Solar-powered Lighting System PCB [16105101]
PCB for the Solar-Powered Lighting System.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
133 x 86.5mm.
|
 |
Compact 12V 20W Stereo Amplifier PCB [01104101]
PCB for the Compact 12V 20W Stereo Amplifier.
It's a single-sided design but is made as a double-sided board so wire links do not need to be installed.
97 x 78mm.
|
 |
Low-Power Car/Bike USB Charger PCB [14105101]
The PCB for the Low-Power Car/Bike USB Charger.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
62 x 49mm
|
 |
Digital Audio Signal Generator main PCB (to suit Jaycar case - 04203101]
The main PCB for the Digital Audio Signal Generator (Jaycar version).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 102mm.
|
 |
Digital Audio Signal Generator main PCB (to suit Altronics case - 04203103]
The main PCB for the Digital Audio Signal Generator (Altronics version).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
109 x 102mm.
|
 |
Digital Audio Signal Generator control PCB [04203102]
The control/front panel PCB for the Digital Audio Signal Generator (both versions).
Single-sided PCB with solder mask and silkscreen overlay.
87 x 73mm.
|
 |
Capacitor Leakage Adaptor PCB [04204101]
The PCB for the Capacitor Leakage Adaptor for DMMs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
145 x 85mm
|
 |
1000:1 EHT Probe PCB [04104101]
The PCB for the EHT Stick.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
228 x 37mm
|
 |
Solar-Powered Intruder Alarm PCB [03103101]
The PCB for the Solar-Powered Intruder Alarm for Sheds & Boats.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
123 x 59mm
|
 |
Low Capacitance Adaptor PCB [04103101]
The PCB for the Low-Capacitance Adaptor for DMMs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
90 x 51mm
|
 |
Milliohm Meter Adaptor PCB [04102101]
PCB for the Milliohm Meter Adaptor for DMMs.
PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
This is the latest version of the PCB which has the errata from October 2010 already fixed.
91.5 x 57mm.
|
 |
Webserver in a Box (WIB) Internet Time Display Module PCB [07102101]
PCB for the WIB Internet Time Display Module.
PCB with plated through holes, solder mask and silkscreen overlay.
76 x 69mm.
|
 |
Stereo DAC Balanced Output Board PCB [01101101]
PCB for A Balanced Output Board For The Stereo DAC.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
110 x 67mm.
|
 |
High-Quality Stereo DAC Input PCB [01109091]
The Input PCB for the High-Quality Stereo Digital-to-Analog Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
113 x 93mm
|
 |
High-Quality Stereo DAC main PCB [01109092]
The DAC PCB for the High-Quality Stereo Digital-to-Analog Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
94 x 110mm
|
 |
High-Quality Stereo DAC front panel PCB [01109093]
The front-panel switch PCB for the High-Quality Stereo Digital-to-Analog Converter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
103 x 34mm
|
 |
One-of-Nine Switch Position Indicator PCB [09112091]
The main PCB for the One-of-Nine Switch Position or track-in-use indicator. Note that the photo shows the completed PCB.
Single-sided PCB with plated through holes, green solder mask and silkscreen overlay.
104 x 62mm.
|
 |
One-of-Nine Switch Position Display PCB [09112092]
The optional display PCB for the One-of-Nine Switch Position or track-in-use indicator. Note that the photo shows the completed PCB.
Single-sided PCB with plated through holes, green solder mask and silkscreen overlay.
35 x 43mm.
|
 |
Twin Engine SpeedMatch Inducator PCB [04111091]
The PCB for the Twin-Engine Speed Match Indicator for Boats.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
105 x 63mm
|
 |
Digital Megohm & Leakage Current Meter PCB [04110091]
The PCB for the Digital Megohm and Leakage Current Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
84 x 102mm
|
 |
6-Digit GPS Clock Autodim Add-On PCB [04208091]
PCB for the 6-Digit GPS Clock Autodim Add-On.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
36 x 19mm.
|
 |
6-Digit GPS Clock Driver PCB [07106091]
Driver PCB for the 6-Digit GPS Clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57mm.
|
 |
6-Digit GPS Clock Main PCB [04105091]
Main PCB for the 6-DIgit GPS Clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
211 x 135mm.
|
 |
Improved Lead-Acid Battery Condition Checker PCB [04108091]
The PCB for the Lead-Acid/SLA Battery Condition Checker.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
185 x 100mm
|
 |
Lead-Acid Battery Zapper and Desulphator Mk.3 PCB [04107091]
The PCB for the Mk.3 Lead-Acid Battery Zapper and Desulphator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
185 x 100mm
|
 |
Hand-Held Metal Locator PCB [04207091]
The PCB for the Hand-Held Metal Locator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
78 x 64mm
|
 |
Multi-Function Active Filter PCB [01107091]
The PCB for the Multi-Function Active Filter Module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
123 x 63mm
|
 |
Beam-Break Flash Trigger PCBs [13106091-2]
Both PCBs for the Beam-Break Flash Trigger.
Double-sided PCBs with plated through holes, solder mask and silkscreen overlay.
122 x 58mm and 57 x 26mm.
|
 |
Input Attenuator PCB for Digital Audio Millivoltmeter [04205091]
Input Attenuator PCB for the Digital Audio Milli-voltmeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 53.5mm.
|
 |
Intelligent Remote-Controlled Dimmer PCB [10104092]
PCB for the Multi-Function, Intelligent Remote-Controlled Dimmer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
This is a double-sided version of the original PCB design which was coded 10104091. As such it does away with the need for wire links and also features a solder mask and silkscreened overlay on both sides.
76 x 50mm.
|
 |
Manual 2-Way USB Device Switch PCB [07104091]
The PCB for the USB Printer Share Switch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
77 x 46mm
|
 |
Theremin Mk.2 PCB [01203091]
The PCB for the New, Improved Theremin.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
147 x 85mm
|
 |
Digital Audio Millivoltmeter PCB [04103091]
Main PCB for the Digital Audio Millivoltmeter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
160 x 111mm.
|
 |
Programmable Time Delay Flash Trigger PCB [13102091]
The PCB for the Time Delay Photoflash Trigger.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
186 x 102mm
|
 |
USB-Sensing Mains Power Switch PCB [10101091]
PCB for the USB-Sensing Mains Power Switch.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
151 x 109mm.
|
 |
Simple Voltage Switch PCB [05112081]
PCB for the Simple Voltage Switch for Car Sensors.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
105.5 x 60.5mm.
|
 |
12V Speed Controller/Lamp Dimmer PCB [05111081]
The PCB for the 12V Speed Controller or 12V Lamp Dimmer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
79 x 47mm
|
 |
Railpower IV main PCB [09109081]
The main PCB for the Railpower IV Model Train Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
217 x 102mm
|
 |
Railpower IV front panel PCB [09109082]
The front panel PCB for the Railpower IV Model Train Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
141 x 71mm
|
 |
LED/Lamp Flasher PCB [11009081]
PCB for the LED/Lamp Flasher.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
62 x 50mm.
|
 |
Planet Jupiter Receiver PCB [06108081]
PCB for the Planet Jupiter Receiver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
117 x 102mm.
|
 |
LED Strobe & Contactless Tachometer main PCB [04108081]
The main PCB for the LED Strobe and Tachometer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
115 x 65mm
|
 |
LED Strobe & Contactless Tachometer button PCB [04108082]
The button PCB for the LED Strobe and Tachometer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
52 x 15mm
|
 |
PIC-based Musical Tuning Aid PCB [04107081]
The PCB for the PIC-based Musical Tuning Aid.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
It's a single-sided design but as the PCB is double-sided, there's no need to fit the wire links - they are already present as top layer copper tracks.
147.5 x 84mm.
|
 |
Balanced Microphone Preamp PCB [01107081]
The PCB for the Balanced Mic Preamp.for PCs & MP3 Players
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
102 x 83mm
|
 |
Balanced/Unbalanced Converter PCB [01106081]
The PCB for the Balanced/Unbalanced Converter for Audio Signals.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The original design is single-sided but the two permanent wire links are replaced with top layer tracks, so they don't need to be installed.
101.5 x 84mm
|
 |
USB Power Injector PCB [07110041]
PCB for the June 2008 version of the USB Power Injector For External Hard Drives.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
76 x 46mm.
|
 |
CDI Module for Small Petrol Motors PCB [05105081]
PCB for the Replacement CDI Module for Small Petrol Motors.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
64 x 45mm.
|
 |
12V Lead-Acid Charge Controller PCB [14104081]
The PCB for the Charge Controller for Lead-acid or SLA Batteries, described in the April 2008 issue.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
101.5 x 78.5mm.
|
 |
Stereo Headphone Adaptor PCB [01104081]
The PCB for the Two-Way Stereo Headphone Adaptor.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
172 x 104mm
|
 |
One Pulse Per Second Driver for Quartz Clocks PCB [04103081]
The PCB for the 1PPS Clock Driver.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
It's a single-sided design but as the PCB is double-sided, there's no need to fit the wire link - it is already present as a top layer copper track.
45.5 x 38mm.
|
 |
Swimming Pool Alarm PCB [03101081]
The PCB for the PIC-Controlled Swimming Pool Alarm.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
102 x 77mm
|
 |
Minispot Oscillator PCB [06101081]
The PCB for the Minispot 455kHz Modulated Oscillator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
72 x 32mm
|
 |
Rolling Code Receiver PCB [01510071]
PCB for the Rolling Code Security System receiver module.
Single-sided PCB with solder mask. The transmitter PCB is not currently available.
61 x 122mm.
|
 |
NiMH Fast Charger PCB [14109071]
The PCB for the Fast Charger for NiMH Batteries.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
98 x 53mm
|
 |
20W Class-A Amplifier Module PCB, left channel [01105071]
Left channel circuit board for the 20W Class A Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. There's no need to install the wire links as top layer tracks take their place.
146 x 80mm.
|
 |
20W Class-A Amplifier Module PCB, right channel [01105072]
Right channel circuit board for the 20W Class A Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. There's no need to install the wire links as top layer tracks take their place.
146 x 80mm.
|
 |
Subwoofer Controller PCB [01108071]
The PCB for the Subwoofer Controller.
Double-sided PCB with solder mask and silk screening. There is no need to fit the wire links as there are top-layer tracks.
198 x 156mm.
|
 |
Knock Detector PCB [05106071]
PCB for the Knock Detector For The Programmable Ignition System.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
96 x 55mm.
|
 |
Programmable Ignition System main PCB [05104071]
Main PCB for the Programmable Ignition System for Cars.
It's a single-sided design but is made as a double-sided board so that wire links do not need to be used.
Note: Trigger Module and Hand Controller PCBs are available separately.
102 x 81mm.
|
 |
Programmable Ignition System Trigger Module PCB [05104072]
Trigger PCB for the Programmable Ignition System for Cars.
It's a single-sided design but is made as a double-sided board so that wire links do not need to be used.
Note: Main PCB and Hand Controller PCB are available separately.
39.5 x 39.5mm.
|
 |
Programmable Ignition System Hand Controller PCB [05104073]
Hand Controller PCB for the Programmable Ignition System for Cars.
It's a single-sided design but is made as a double-sided board so that wire links do not need to be used.
Note: Main PCB and Trigger Module PCB are available separately.
115 x 65mm.
|
 |
VU/Peak Meter main PCB [01205071]
The main PCB for the VU/Peak Meter with LCD Bargraphs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
116 x 65mm
|
 |
VU/Peak Meter button PCB [01205072]
The button PCB for the VU/Peak Meter with LCD Bargraphs.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
81 x 19mm
|
 |
Variable Boost Controller PCB [05102072]
The PCB for the Simple Variable Boost Controller for Cars with Turbochargers.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
38 x 30mm
|
 |
Fuel Cut Defeater PCB [05102071]
The PCB for the Fuel Cut Defeater for Cars with Variable Boost Control.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
50 x 33mm
|
 |
Car Air Conditioner Controller PCB [05101071]
The PCB for the Intelligent Car Air-Conditioner Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The link does not need to be fitted as it is replaced with a top layer track.
107 x 61mm
|
 |
Cordless Power Tool Charger Controller PCB [14112061]
PCB for the Cordless Power Tool Charger Controller (14112061).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
79 x 47mm.
|
 |
CPR Trainer PCB [04112061]
The PCB for the Heartbeat CPR Training Beeper.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
46 x 53mm
|
 |
LED Tachometer Control PCB [05111061]
The Control PCB for the LED Tachometer with Dual Displays.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
117 x 101mm.
|
 |
LED Tachometer Display PCB [05111062]
The Display PCB for the LED Tachometer with Dual Displays.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
89mm diameter.
|
 |
RIAA Preamplifier PCB [01108061]
PCB for the Magnetic Cartridge Preamplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
102 x 81mm.
|
 |
Ultrasonic Eavesdropper PCB [01208061]
PCB for the Ultrasonic Eavesdropper.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57mm.
|
 |
Mini Theremin Mk.2 PCB [01207061]
The PCB for the Mini Theremin Mk2.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
188 x 103mm
|
 |
Pocket A/V Test Pattern Generator PCB [PAVTSG]
The PCB for the Pocket AV Test Pattern Generator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
62.5 x 76.5mm.
|
 |
Studio Series Remote Control Module PCB [01104061]
The Remote Control PCB for the Studio Series Preamplifier. We do not recommend building this unless you are making the Studio Series Preamp.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
150 x 72mm
|
 |
Pocket TENS Unit PCB [11101061]
PCB for the Pocket TENS (Transient Electrical Nerve Stimulation) Unit.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
85 x 64mm.
|
 |
"Little Jim" AM Transmitter PCB [06101062]
PCB for the "Little Jim" AM Radio Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
122 x 57.5mm.
|
 |
Studio Series Headphone Amplifier PCB [01111051]
The Headphone Amplifier PCB for the Studio Series Preamplifier. Could also be used as a standalone headphone amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be fitted as they are replaced with top layer tracks.
134 x 103mm
|
 |
Studio Series Stereo Preamplifier main PCB [01109051]
Main PCB for the Studio Series Preamplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
192 x 73mm.
|
 |
Bilge Sniffer/Alcohol Meter PCB [05109051]
The PCB for the Bilge Sniffer or Simple Alcohol Meter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
123 x 60mm
|
 |
Programmable Flexitimer main PCB [04108051]
The main PCB for the Programmable Flexitimer.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be installed as they are replaced with top layer tracks.
141 x 83mm
|
 |
Programmable Flexitimer display PCB, DSE version [04108052]
The display PCB for the Programmable Flexitimer, to suit the Dick Smith LCD. It looks like a typical 16x2 LCD module will fit on this PCB but you'd need to verify that.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be installed as they are replaced with top-layer tracks.
132 x 84mm
|
 |
Programmable Flexitimer display PCB, Altronics version [04108054]
The display PCB for the Programmable Flexitimer, to suit the Altronics Z7011 LCD.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be installed as they are replaced with top layer tracks.
132 x 84mm
|
 |
TwinTen Amplifier PCB [01102051]
The PCB for the TwinTen Stereo 10W Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. The links do not need to be installed as they are replaced with top layer tracks.
215 x 156mm
|
 |
IR Remote Control Checker PCB [04101051]
The PCB for the IR Remote Control Checker.
Double-sided PCB (single-sided design) with plated through holes, green solder mask and silkscreen overlay.
112 x 57mm.
|
 |
Schoolies' 20W Amplifier Module PCB [01112041]
The PCB for the Schoolies' 20W Amplifier.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
82.5 x 66mm.
|
 |
Video Enhancer & Y/C Separator PCB [02108041]
The PCB for the Video Enhancer & Y/C Separator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
198 x 157mm.
|
 |
Balanced Microphone Preamp PCB [01108041]
PCB for the Balanced Microphone Preamplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
102 x 89mm
|
 |
Dr Video Mk2 PCB [02106041]
The PCB for the Dr Video Mk.2 Video Stabiliser.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
117 x 102mm.
|
 |
Poor Man's Metal Locator PCB [04105041]
PCB for the Poor Man's Metal Locator.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
51 x 64mm.
|
 |
Studio 350 Power Amplifier PCB [01102041]
PCB for the Studio 350 Power Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
This includes the shelf section, which can be cut off if used with a vertical heatsink. Top layer tracks have been added to improve current handling capability and eliminate the need for any wire links.
241.5 x 136mm.
|
 |
12AX7 Valve Audio Preamplifier Main PCB [01111031]
Main PCB for the 12AX7 Valve Audio Preamplifier.
Suitable for both the original Valve Preamplifier (November 2003) and the Hifi version (February 2004).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
125 x 62mm.
|
 |
12AX7 Valve Audio Preamplifier Power Supply PCB [01111032]
Power Supply PCB for the 12AX7 Valve Audio Preamplifier.
Suitable for both the original Valve Preamplifier (November 2003) and the Hifi version (February 2004).
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
125 x 62mm.
|
 |
Lapel Mic Adaptor PCB (Altronics case version) [01101042]
The Altronics PCB for the Lapel Microphone Adaptor for PA Systems. The cut-out for the XLR connector is already made.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
80.5 x 72mm.
|
 |
VHF Receiver for Weather Satellites PCB [06112031]
PCB for the VHF Receiver for Weather Satellites.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
117 x 102mm.
|
 |
Smart Slave Flash Trigger PCB [13107031]
PCB for the Smart Slave Flash Trigger.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
45 x 76mm.
|
 |
Programmable Continuity Tester PCB [04207031]
The PCB for the Programmable Continuity Tester.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
70 x 55mm
|
 |
SC480 amplifier module PCB, TO-218 transistor version [01201031]
The PCB for the plastic transistor version of the SC480 audio amplifier module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Top-layer tracks are provided instead of wire links, although links can be added if desired.
119.5 x 90mm.
Note: we recommend building the SC200 instead (PCB and hard-to-get parts also available) as it performs better and is easier to build.
|
 |
SC480 amplifier module PCB, TO-3 transistor version [01201032]
The PCB for the TO-3 metal can transistor version of the SC480 audio amplifier module.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Top-layer tracks are provided instead of wire links, although links can be added if desired.
150 x 118.5mm.
Note: we recommend building the SC200 instead (PCB and hard-to-get parts also available) as it performs better and is easier to build.
|
 |
SC480 amplifier module power supply PCB [01201033]
The power supply PCB for the SC480 audio amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
54.5 x 90mm.
Note: we recommend building the SC200 instead (PCB and hard-to-get parts also available) as it performs better and is easier to build.
|
 |
Micromitter FM Stereo Transmitter PCB [06112021]
PCB for the Micromitter FM Stereo Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
78 x 50mm.
|
 |
50-Watt DC Electronic Load PCB [04109021]
The PCB for the Simple 50W DC Electronic Load.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
93.5 x 58mm.
|
 |
Remote Volume Control PCB [15106021]
The PCB for the Remote Volume Control for Stereo Amplifiers.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design). Top layer tracks mean you don't need to install any wire links on this board.
74 x 57mm.
|
 |
Multi-Power main PCB [04104021]
The main PCB for the Multi-Power easy-to-build bench power supply.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay. It is not necessary to install the wire links on this board, as they are replaced with top-layer tracks.
119.5 x 124.5mm.
|
 |
Multi-Power front panel PCB [04104022]
The front panel PCB for the Multi-Power easy-to-build bench power supply.
Single-sided PCB with green solder mask and silkscreen overlay.
133.5 x 48mm.
|
 |
RIAA Preamplifier PCB [01303021]
The PCB for the RIAA Preamplifier for Magnetic Cartridges from March 2002, with onboard power supply including a PCB-mounting mains transformer.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay. Most of the wire links (except the Earth link) do not need to be fitted as the PCB has a top-layer track instead.
67 x 215mm.
|
 |
Minimitter FM Stereo Transmitter PCB [06104011]
PCB for Minimitter FM Stereo Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
153 x 60mm.
|
 |
Big-Digit 12/24-Hour Clock display PCB [04103012/04102011]
The display PCB for the B-I-G digit 12/24-hour clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design).
Top layer tracks mean you don't need to install any wire links on this board. However, since not all links are used in all cases, you will likely need to cut the unwanted tracks with a sharp knife.
233 x 76mm. Note that two different codes have been used for this board in different places.
|
 |
Big-Digit 12/24-Hour Clock processor PCB [04103011]
The processor PCB for the B-I-G digit 12/24-hour clock.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay (single-sided design). Top layer tracks mean you don't need to install any wire links on this board.
233 x 76mm.
|
 |
15W Class-A Amplifier module PCB [01207981]
The amplifier module circuit board for the 15W Class A Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Top layer tracks have been added so you shouldn't need to fit the wire links.
120 x 81mm.
|
 |
15W Class-A Amplifier power supply PCB [04208981]
The power supply circuit board for the 15W Class A Amplifier.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Top layer tracks have been added so you shouldn't need to fit the wire links.
97 x 76mm.
|
 |
Heat Controller PCB [10307981]
PCB for the Heat Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
85 x 79mm.
|
 |
Heavy-Duty 10A 240VAC Motor Speed Controller PCB [10311971]
The PCB for the Heavy Duty 10A 240V AC Motor Speed Controller.
Single-sided PCB with plated through holes, solder mask and silkscreen overlay.
112 x 144mm.
|
 |
Flickering Flame PCB [11410971]
The PCB for the Flickering Flame project.
Double-sided PCB (single-sided design) with plated through-holes, black solder mask and silkscreen overlay
58 x 38mm.
|
 |
Audio/RF Signal Tracer PCB [04106971]
The PCB for the Audio/RF Signal Tracer.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
53 x 55mm.
|
 |
600W DC-DC Converter PCB [05308961]
The main PCB for the 600W DC-DC Converter for Car Hifi Systems.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay.
305 x 214.5mm.
|
 |
Low-Power Electric Fence Controller PCB [11306951]
The PCB for the July 1995 Electric Fence Controller.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
171 x 79mm.
|
 |
FM Subcarrier Decoder PCB [06303951]
The PCB for the Subcarrier Decoder for FM Receivers.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. Top layer tracks replace the four links so you don't need to install them.
137 x 80mm
|
 |
Dual Electronic Dice PCB [08105941]
The PCB for the Dual Electronic Dice.
Double-sided PCB with plated through holes, green solder mask and silkscreen overlay. Top layer tracks have eliminated the need for wire links.
101.5 x 112mm
|
 |
Low-Noise Universal Stereo Preamplifier PCB [01106941]
The PCB for the Low Noise Universal Stereo Preamplifier.
Double-sided PCB (single-sided design) with plated through holes, solder mask and silkscreen overlay.
80 x 77.5mm.
|
 |
AM Radio Transmitter PCB [06112921]
PCB for the AM Radio Transmitter.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
102 x 53mm.
|
 |
Multi-Station Headset Intercom PCB [01302921]
PCB for the Multi-Station Headset Intercom.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay. It's a single sided design and as the board is manufactured with two layers, you don't need to fit wire links.
89 x 91.5mm.
|
 |
Water Tank Level Indicator PCB [05104022]
PCB for the Multi-Station Headset Intercom.
Double-sided PCB with plated through holes, solder mask and silkscreen overlay.
80 x 50mm.
|
